The Application Research on Three-Dimensional GPR Image Used in Grouting Effect Evaluation of Subgrade Void

Abstract:

On the basis of the GPR method principle, data acquisition and processing, this paper mainly discusses two-dimensional GPR profiles and three-dimensional GPR images through GPR detection example about the voids of highway bridge head subgrade and the grouting distribution. Three-dimensional images accurately and directly evaluate the grouting effect. Thus it illustrates that GPR used to detect the voids of highway bridge head roadbed and the grouting distribution is an effective method.

• Periodical: Advanced Materials Research (Volumes 1065-1069)
• Pages: 725-732
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1065-1069.725
• Online since: December 2014
• Authors: Yong Qing Yang
• Keywords: GPR, Grouting Distribution, Three-Dimensional Image, Void
