The Improvement about the Reliability of Sampling Based on Process Bus in Smart Substation

Abstract:

The sampling based on process bus is not widely used in smart substation because there are still some technical problems on synchronization, the design of network architecture and sampling data receiving and processing areas. There are some researches about the problems are carried out, but they only focus on part of them and cannot give the whole solution. In order to improve the reliability of network sampling, a new system method which includes all the segments of the sampling based on process such as the synchronization of data acquisition, data transmission, network optimization and data processing are presented. In the data acquisition segment, the synchronization based on IEEE1588 is provided, In the data transmission segment, a new hardware architecture which is based on FPGA+DSP+VxWorks is described, in the segment of network optimization, the topology structure and virtual LAN are suggested. At last, the automatic resampling is proposed in the data receiving and processing segment. It will be useful to improve the reliability of sampling based on process bus in smart substation.

• Periodical: Advanced Materials Research (Volumes 1070-1072)
• Pages: 1398-1404
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1070-1072.1398
• Online since: December 2014
• Authors: Chen Fan*, Yi Min Ni, Ren Hui Dou, Xin Xu, Zhi Qiang Yao, Guo Qing Zhao
• Keywords: IEC61850, IEEE1588, Process Bus, Smart Substation, VLAN

References

[1] Steve Hodder, Bogdan Kasztenny, David McGinn, Rich Hunt, GE Multilin. IEC 61850 process bus solution addressing business needs of today's utilities[C], in Power Systems Conference, Clemson, SC, (2009).

DOI: 10.1109/psamp.2009.5262419

[2] A. Apostolov, B. Vandiver. IEC 61850 process bus - principles, applications and benefits[C], Protective Relay Engineers, 2010 63rd Annual Conference, March 29 2010-April 1 (2010).

DOI: 10.1109/cpre.2010.5469489

[3] Chiara Maria De Dominicis, Paolo Ferrari, Alessandra Flammini, Stefano Rinaldi. On the Use of IEEE 1588 in Existing IEC 61850-Based SASs Current Behavior and Future Challenges[J], IEEE transactions on instrumentation and measurement, Vol. 60, No. 9, September (2011).

DOI: 10.1109/tim.2011.2158159

[4] Jim McGhee, Maciej Goraj. Smart High Voltage Substation Based on IEC 61850 Process Bus and IEEE 1588 Time Synchronization[C], Smart Grid Communications (SmartGridComm), 2010 First IEEE International Conference on 4-6 Oct. (2010).

DOI: 10.1109/smartgrid.2010.5622092

[5] David M.E. Ingram, Pascal Schaub, Duncan A. Campbell. Use of Precision Time Protocol to Synchronize Sampled-Value Process Buses[J], IEEE transactions on instrumentation and measurement, Vol. 61, No. 5, May (2012).

DOI: 10.1109/tim.2011.2178676

[6] Jean-Charles Tournier, Thomas Werner. A quantitative evaluation of IEC61850 process bus architectures [C]. in IEEE Power and Energy Society General Meeting. (2010).

DOI: 10.1109/pes.2010.5588205

[7] The State Grid Corporation of China. The Technical specification of relay protection in smart substation[S], BeiJing，(2010).

[8] FAN Chen, NI Yi-min, SHEN Jian. Research on the application of IEEE1588 in the merging unit based on IEC61850-9-2[J]. Automation of Electric Power Systems, 2011, 35(6): 55-58.

[9] YU Peng-fei, YU Qiang, DENG Hui. The Research of Precision Time Protocol IEEE1588[J]. Automation of Electric Power System, 2009，33（13）: 99-103.

[10] XIE Li, HUANG Guo-fang, SHEN Jian. Design of high accuracy synchronous sampling clock in digital substations[J]. Automation of Electric Power Systems, 2009，33（1）: 61-65.

[11] FAN Chen, NI Yimin, DOU Renhui, SHEN Jian, GAO Chunlei, HUANG Guofang. Analysis of network scheme for process layer in smart substation[J]. Automation of Electric Power Systems, 2011, 35（18）: 67-71.

[12] T.S. Sidhu，Yujie Yin. Modelling and simulation for performance evaluation of IEC61850- based substation communication systems[J]. IEEE Transaction on power delivery, 2007, 22(3): 1482-1489.

DOI: 10.1109/tpwrd.2006.886788

[13] XU Guanghui, LI Youjun, WANG Wenlong. Design of a synchronization and interpolation algorithm of samled values for digital substation IED[J]. Automation of Electric Power Systems, 2009, 33（4）: 49-52.

[14] ZHOU Bin, LU Guogang, HUANG Guofang. A sampled values interface method for substation IED based on the linear lagrange interpolation algotithm[J]. Automation of Electric Power Systems, 2007, 31（3）: 86-90.

[15] Mitalkumar G. Kanabar, Tralochan S. Sidu. Performance of IEC61850-9-2 process bus and corrective measure for digital relaying[J] IEEE transactions on power delivery, Vol. 26, No. 2, April (2011).

DOI: 10.1109/tpwrd.2009.2038702
