Research on Inverter Side Steady Operation of Direct-Drive Permanent Magnet Synchronous Wind Power System

Abstract:

Currently, back-to-back converter is widely used in rectifier and inverter of direct-drive permanent magnet synchronous wind power system. But there are two shortages in the system, not stable of control effect and higher ripple of DC voltage. The dual-channel parallel boost converter can shunt the DC current, reduce the ripple effectively, and improve the quality of inverter side DC current. The paper uses the space vector pulse width modulation control strategy to control the inverter. Simplifying and decoupling the complex control system and control the DC bus voltage to remain stable. The simulation results confirm that dual-channel parallel boost converter have a better control effect than back to back converter, it through control the inverter to make power quality reached the grid connected requirement, verified the correctness of the design of inverter.

• Periodical: Advanced Materials Research (Volumes 1070-1072)
• Pages: 204-208
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1070-1072.204
• Online since: December 2014
• Authors: Ruo Fa Cheng, Li Hu Chen*, Xin Hong Yu, Yin Ping Ma
• Keywords: Dual-Channel Parallel Boost Converter, Grid Voltage Angle, Inverter, Space Vector Pulse Width Modulation

References

[1] Shuangxi Zhou, Zongxiang Lu. Wind power and power system,. China electric power press, beijing of China (2011).

[2] Feng Gao, Xiaoxin Zhou. Electromechanical Transient Modeling and Simulation of Direct-Drive Wind Turbine System with PMSG. Power System Technology. Publish in China (2011).

[3] Gangui Yan, Zhicheng Wei. Dynamic Modeling and Control of DPMSG Wind Turbine. Proceedings of the CSU-EPSA. Publish in China (2009).

[4] Xunbo Fu, Jindong Guo and Dongli Zhao, The simulation of DPMSG. Electric Power Automation Equipment. Publish in China (2009).

[5] X.J. Song. Comparison between id=0 vector controller and feedback linearization controller [J], Automation & Instrumentation. Publish in China (2013).

[6] Y.L. Wang. The feedback linearization control system research of PMSG, jiangnan university, Fer. (2006).

[7] Bin Wu, Yougqiang Lang, Navid Zargari and Samir Kouro. Power Conversion and Control of Wind Energy Systems, IEEE Press, p.275~276, (2011).

DOI: 10.1002/9781118029008

[8] Lulian Munteanu, Antoneta luliana Bratcu et. al. Optimal Control of Wind Energy Systems[M] , China machine press. p.125~131, (2011).
