The Effect of Digital Process of Single-Phase Photovoltaic Grid Connected Inverter

Abstract:

Digital control possesses evident advantages and has become a mainstream control of photovoltaic grid connected inverter.The mathematical model and parameter setting of the single phase photovoltaic grid connected inverter with L filter was introduced in the paper.It was analysed on the effect on system stability of digital process from the two aspects which were the zero-order-hold and one-step-delay control. The bode diagram was verified the theoretical analysis on system stability.The conclusions were made that the introduction of digital control reduces the critical stable gain of photovoltaic grid connected inverter system,system stability is varied with sample time, the parameters of L can affect the system stability range,zero-order-hold reduces the stability range and limits the performance improved of digital control system,one-step-delay control on photovoltaic grid connected inverter reduces again the stability range on the basis of the zero-order-hold control.

• Periodical: Advanced Materials Research (Volumes 1070-1072)
• Pages: 60-63
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1070-1072.60
• Online since: December 2014
• Authors: Hong Tao Shan*, Bin Zhou
• Keywords: Grid Connected Inverter, L-Filter, One-Step-Delay Control, Zero-Order-Hold

References

[1] Mohammand S.J. Asghar, Adiln Sarwar, Smart Grid and Renewable Energy, 2011, Vol. 02(01), pp.56-62.

[2] Li Peng; Kai Zhang; Yong Kang; Jian Chen. APEC'06, 2006: 798-803.

[3] Tao Zhang. Research on Control of Single Phase LCL Filter Grid-Connected Interver. Yan Shan University, (2009).

[4] L. Asiminoaei,E. Aeloiza J.H. Kim: An Interleaved Active Power Filter with Reduced Size of Passive Components. Proc. APEC'06, (2006).

DOI: 10.1109/apec.2006.1620656

[5] S.G. Xu: electric welding machine, vol. 3(2008) p.60–62, In Chinese.

[6] Hongtao Shan, Yong Kang, Xuejuan Kong, Zhao Liu, Mi Yu, Hongbo, Li, Fang Luo, Liming Liu. INTELEC 2008symposium: 706-711.

DOI: 10.1109/intlec.2008.4664127
