Stability Analysis of Latticed Shells

Abstract:

ANSYS14.0 structural analysis software is used in order to make a ring rib-reticulated shell for the overall stability analysis. Considering the geometric nonlinear analysis and initial geometric imperfections influence , obtain a key node of the load - displacement curve and assess the ultimate strength of the structure. The results showed that: the structure meets the "Space grid rules" for monolayer shells stability requirements. And it is found that load distribution form and initial geometry defect has a great deal whit bearing capacity of single-layer lattice shell stability by comparison.

• Periodical: Advanced Materials Research (Volume 1078)
• Pages: 220-223
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1078.220
• Online since: December 2014
• Authors: Wen Bin Shi*
• Keywords: Geometric Nonlinearity, Latticed Shell, Load - Displacement Analysis of the Entire Process

References

[1] Yanzu Shen, Yangji Chen. Grid and lattice shell [M] Tongji University Press, Shanghai, 1997: 190-195.

[2] Deiyu yin, Shanwei Liu, Ruojun Tie, network shell structure design [M]. Beijing: China Building Industry Press, (1996).

[3] Shizhao Shen, Xin Chen, stability of reticulated shells [M] Beijing: Science Press, (1999).
