Numerical Simulation of Impact Loading on Solid Propellant within an Orthotropic Shell

Abstract:

The strain-stress state of the solid propellant rocket engines (SPRE) is simulated under impact. Orthotropic organoplastic is the material of the shell. The effect of orientation of elastic and strength properties of the shell material on the strain-stress state of the solid propellant is investigated. Normal interaction of single steel cylinder strikers and oblique impact, both simultaneous and at different times of multiple, converging steel spheric particles with SPRE are considered in the work. The investigation is conducted numerically. The numerical modeling was carried out in three-dimensional statement by a method of finite elements in frameworks of the continual approach of the mechanics of deformable solid. The destruction of the anisotropic material is described by tensor polynomial criterion of the fourth degree, which takes into account the influence of hydrostatic pressure.

You might also be interested in these eBooks

Prospects of Fundamental Sciences Development

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 1085)

Pages:

486-491

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.1085.486

Citation:

Cite this paper

Online since:

February 2015

Authors:

Pavel Radchenko*, Andrey Radchenko, Stanislav Batuev

Keywords:

Anisotropic Material, Detonation, Failure, Impact, Pressure, Properties Orientation, Shell, Solid Propellant, Strain Rate, Strength, Stress

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] G.K. Ashkenazi, E.V. Ganov, Anisotropy of construction materials. Engineering Industry Press. Leningrad, (1980).

Google Scholar

[2] A.V. Radchenko, S.V. Kobenko, I.N. Marcenuk, I.E. Khorev, G.I. Kanel, V.E. Fortov. Research on features of behaviour of isotropic and anisotropic materials under impact, In Jour of Impact Eng. 23 (1999) 745-756.

DOI: 10.1016/s0734-743x(99)00119-0

Google Scholar

[3] G.R. Johnson. High Velocity Impact Calculations in Three Dimension. J. App. Mechanics. 3 (1977) 95-100.

Google Scholar

[4] A.V. Radchenko. Model of behavior of brittle anisotropic materials at dynamic loads and ist applications. Vestnik Tomskogo gosudarstvennogo arkhitekturno-stroitelnogo universiteta (in Russian). 2 (2003) 179-193.

DOI: 10.31675/1607-1859-2018-20-4-111-121

Google Scholar

[5] A.V. Radchenko, M.N. Krivosheina, P.A. Radchenko, S.V. Kobenko, E.N. Aftaeva. Model of behavior of brittle anisotropic materials at dynamic loads and ist applications. Vestnik Tomskogo gosudarstvennogo arkhitekturno-stroitelnogo universiteta (in Russian). 2 (2003).

DOI: 10.31675/1607-1859-2018-20-4-111-121

Google Scholar
