Research on Performance of Drilling Carbon Fiber Reinforced Plastics with Diamond Coated Special Drill

Abstract:

The carbide cemented special drills with TiAlCrN/TiSiN coating and diamond coating respectively were selected to drilling on carbon fiber reinforced plastics (CFRP) for a contrast test in this paper. The drilling force , drilling exit surface quality and tool wear were analyzed separately to research the performance characteristics of the two kinds of special drills with different coating. The results show that: under the same cutting conditions, the thrust force of the special drill with diamond coating is smaller than that of the TiAlCrN/TiSiN coating, and the tool life is extended by 2 times at the same time. The diamond coated special drill can improve the drilling surface quality, it is more suitable for drilling CFRP.

• Periodical: Advanced Materials Research (Volume 1088)
• Pages: 733-738
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1088.733
• Online since: February 2015
• Authors: Xiao Fan Yang*, You Sheng Li, Zhi Long Xu, Ju Dong Liu, Bi Jin Wu
• Keywords: Carbon Fiber Reinforced Plastics (CFRP), Diamond Coating, Special Drill, Tool Life

References

[1] Li Wei, Guo Quanfeng. Application of carbon fiber composites to cosmonautic fields [J]. Chinese Optics, 2011, 4(3): 201-212.

[2] Abrao A M, Faria P E, Campos Rubio J C, et al. Drilling of fiber reinforced plastics: A review [J]. Journal of materials processing technology, 2007(186): 1-7.

[3] Tsao C C, Hocheng H. Evaluation of thrust force and surface roughness in drilling composite material using Taguchi analysis and neural network[J]. Journal of materials processing technology，2008(203)：342-348.

DOI: 10.1016/j.jmatprotec.2006.04.126

[4] Paulo Davim J. A note on the determination of optimal cutting conditions for surface finish obtained in turning using design of experiments. Journal of materials processing technology, 2001, 116(2-3): 305-308.

DOI: 10.1016/s0924-0136(01)01063-9

[5] Li Gui-yu, LI Jian-feng, Sun Jie, et al. Process of drilling carbon fiber reinforced composite with cemented carbide drill [J]. Materials Science and Engineering of Powder Metallurgy, 2010, 15(6): 580-585.

[6] Ren Shunan，Wu Dan，Chen Ken. Thrust force on the main cutting edge when cutting carbon fiber reinforced plastics [J]. Tsinghua University(Sci＆Tech), 2013, 53（4）: 487-492.

[7] Mu Juan, Chen Yan, Xu Jiuhua. Analysis on Cracking at Exit of Hole Drilled in Carbon Fiber Reinforced Plastics Laminate with Brazed Diamond Core Drill [J]. China Mechanical Engineering. 2013, 20(10): 2699-2704.
