Application of Concrete Filled Steel Tubular Supports in the Shaft Station

Abstract:

In order to solve the issues of large deformation and difficult to support in Lu Cun coal mine-270m level shaft station, the reasons of damage to the original roadway supporting conditions have been analyzed through the field investigations. A composite supporting scheme which depend mostly on concrete-filled steel tubular (CFST) supports, spray the anchor net and surrounding rock grouting reinforcement technology as a supplement was designed. The cross-section of the supports is circular. The main steel pipe is 20^# seamless steel pipe with diameter of 194mm and wall thickness of 8mm. It is shows that the composite supports can effectively control the deformation of surrounding rock of roadway and maintain long-term stability.

• Periodical: Advanced Materials Research (Volume 1089)
• Pages: 213-218
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1089.213
• Online since: January 2015
• Authors: Hao Xie*, Feng Yin Zhang, He Guo, Bao Sen Zhang
• Keywords: Anchor Net Spray, Concrete-Filled Steel Tubular Supports, Shaft Station, Surrounding Rock Grouting

References

[1] Manchao He, Heping Xie and Suping Peng et al: The research on deep mining rock mechanics (in Chinese) [J]. Chinese Journal of rock mechanics and Engineering, 2005, 24(16): 2803-2813.

[2] Jucai Chang, Guangxiang Xie: Deep roadway surrounding rock mechanics characteristics and stability study (in Chinese) [J]. Journal of China Coal Society, 2009, 34(7): 881-886.

[3] Xiaoming Sun, Manchao He, Guofeng Zhang et al: The destructive force of soft rock roadway mechanism and Countermeasures of Hebi Minerals (in Chinese) [J]. Journal of Liaoning Technical University (Natural Science Edition), 2009, 28(3): 393-396.

[4] Yanfa Gao, Jun Wang, Wanpeng Huang et al: The straight wall arch steel tube scaffold mechanical properties of concrete experiment and application (in Chinese) [J]. Tunnel Construction Magazine, 2014, 34(1): 6-12.

[5] Yanfa Gao, Bo Wang, Jun Wang et al: Performance test and application of concrete filled steel tubular structure in soft rock roadway in deep mine (in Chinese) [J]. Chinese Journal of rock mechanics and Engineering, 2010, 29(1): 2604-2609.

[6] Jun Wang: Experimental study on flexural mechanical properties and engineering application of the concrete filled steel tube arches (in Chinese) [D]. Beijing: China University of Mining & Technology, Beijing, (2014).

[7] Bo Wang: Mechanism analysis and concrete filled steel tube scaffold supporting technology of deformation of soft rock roadway (in Chinese) [D]. Beijing: China University of Mining & Technology, Beijing, (2009).

[8] Guo Lei: Study on the supporting theory to enhance the performance of concrete filled steel tubular scaffold with soft rock roadway pressure ring (in Chinese) [D]. Beijing: China University of Mining & Technology, Beijing, 2013: 65-89.

[9] Hongpu Kang, Zhiqiang Feng: Reinforcing the status and development trend of technology in coal mine roadway surrounding rock grouting(in Chinese) [J]. Coal Mining Technology, 2013, 18(3): 1-7, 10.
