High Capacity High-Speed Switch Application Analysis and Action Process Simulation

Abstract:

This paper analyzed high capacity high speed switch’s works and structures, proposed a parallel structure of high capacity high speed switch (FSR) with current limiting reactor. Through analysis of its action process, this paper used EMTP/ATP to simulate FSR action process, analyzed line current and voltage changes in normal and short circuit station. Simulation results show that the method can effectively limit short circuit current level.

• Periodical: Advanced Materials Research (Volumes 1092-1093)
• Pages: 276-280
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1092-1093.276
• Online since: March 2015
• Authors: Tie Ying Zhao*, Jun Ling Liu
• Keywords: Current Limiting Reactor, EMTP/ATP, FSR
