Switched Reluctance Wind Generation System Based on Z Source Inverter

Abstract:

This paper uses Z source inverter in switched reluctance wind power generation (SRWPG) to connect to power grid. According to operation of switched reluctance generator (SRG), requirements of grid-connection and the unique single stage buck boost feature of Z source inverter, Z source inverter with space vector pulse with modulation (SVPWM) is adopted to satisfy the voltage level of grid-connection. A control method of grid-connection inverter is developed to keep the capacitor voltage of Z source inverter stable and regulate the active and reactive power. Simulation of SRG and Z source inverter are constructed based on MATLAB/Simulink platform. Simulation results reveal that Z source inverter is feasible and valuable in wind power generation on SRG system.

• Periodical: Advanced Materials Research (Volumes 1092-1093)
• Pages: 96-103
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1092-1093.96
• Online since: March 2015
• Authors: Yi Xiang Shao*, Xiao Ling Yuan, Wei Tian
• Keywords: SVPWM, Switched Reluctance Generator, Wind Power Generation, Z Source Inverter

References

[1] Huang Zhao, Yi Lingzhi, Peng Haimei and Li Jucheng. Research about Application of Space-Vector Modulation Inverter Technique in Switched Reluctance Generator for Wind Power System. Measurement and Testing Technology. Vol. 35 (2008), pp.12-15+18.

[2] Xie Shuanqin, Zhang Zhen, Shi Wei and Zhang Lei. Simulation and Research of Grid-Connected Inverter in SRG Power System. Measurement and Control Technology. Vol. 30 (2011), pp.68-71.

[3] Peng F Z. Z-source Inverter. IEEE Transactions on Industry Applications, Vol. 39 (2003), pp.504-510.

[4] Zhao Ergang, Cheng Ruqi, Guo Tianyong, Liang Kai, Zhao Yao, Wang Qingzhang and Zhao Gengshen. SVPWM Technique Applied to Z-source Inverter. Acta Scientiarum Naturallum (Universitatis Nakaiensis). Vol. 01 (2009), pp.76-79.

DOI: 10.1109/peits.2009.5406811

[5] Xu Po, Zhang Xing, Zhang Chongwei, Cao Renxian and Zhao Wei. Small Wind Turbine Grid-Connected Systems Based on Z-Source Inverter. Transactions of China Electrotechnical Society. Vol. 04 (2008), pp.93-97.

[6] Dusonchet L, Massaro F and Telaretti E. Transient Stability Simulation of a Fixed Speed Wind Turbine by Matlab/ Simulink. Clean Electrical Power. International Conference. (2007), pp.651-657.

DOI: 10.1109/iccep.2007.384308

[7] Xue Bicui, Zhang Chenghui and Ding Xinping. Analysis and Comparison of PWM Modulation Strategies for Z-source Inverter. Advanced Technology of Electrical Engineering and Energy. Vol. 03 (2013), pp.95-100+109.

[8] Peng Hanmei, Yi Lingzhi and Zhu Jianlin. Study and Simulation for Switched Reluctance Generator Output Voltage Ripple Reduction. Journal of System Simulation. Vol. 22 (2010), pp.1237-1241.
