The Effect of Dry Granulating Machine Spindle Eccentricity on the Granulation

Abstract:

For the dispersity of particles in the process of ceramics dry granulating, simulating the effect of spindle eccentricity on it based on the Euler-Euler model. Simulation results show that the volume fraction of particles in the granulating chamber were 52%, 53%, 51% when the spindle eccentricity were 15mm, 25mm, 35mm. For particles distribute in the region of packing density above 0.4kg/m3 , the volume fraction in the granulating chamber were 11%, 3%, 7%. Therefore, spindle eccentricity has little effect on the whole the volume fraction of particles, but the effect on particles distribute in the region of packing density above 0.4kg/m3 is larger .Particles dispersity is best in the process of granulating when spindle eccentricity is 30mm.

You might also be interested in these eBooks

Chemical, Material and Metallurgical Engineering IV

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 1094)

Pages:

374-378

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.1094.374

Citation:

Cite this paper

Online since:

March 2015

Authors:

Nan Xing Wu*, Tian Tian Zhan, Da Hai Liao

Keywords:

Ceramics Dry Granulating, Dispersity, Euler-Euler Model, Spindle Eccentricity

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

* - Corresponding Author

References

[1] Li Shaoyong, Zhou Rongguang, Ling Feifeng. Ultrafine Dry Granulation Preparation Technology of Ceramic Powder. Foshan ceramics[J]. 2011(08): 20-22.

Google Scholar

[2] Shinde Namdeo, Aloorkar Nagesh, Kulkarni Ajit, et al. Recent Advances in Granulation Techniques[J]. Asian Journal of Research in Pharmaceutical Science. 2014, 4(1): 38-47.

Google Scholar

[3] Zhou Shaoping, Ge Xiaoling. Study on Aggregation Mechanism and Fractal Characteristic of Ultra-fine TiO2 [J]. BULLETIN OF THE CHINESE CERAMIC SOCIETY. 2013, 32(08): 1680-1683.

Google Scholar

[4] Yuelin Qin, Xuewei Lv, Chenguang Bai, et al. Dry Granulation of Molten Slag using a Rotating Multi-Nozzle Cup Atomizer and Characterization of Slag Particles [J]. Steel Research International, 2013, 84(9): 852–862.

DOI: 10.1002/srin.201200325

Google Scholar

[5] Nanxing Wu, Xing Bao, Dahai Liao, et al. Analysis of Temperature Field on Ceramic Dry Granulation Machine [J]. Advanced Materials Research. 2014, 951(49): 49-52.

DOI: 10.4028/www.scientific.net/amr.951.49

Google Scholar

[6] KONG Haifa, The Answering of Questions About Dry Granulation Technology Applied in Ceramic Industry [J]. Foshan ceramics. 2008(09): 43-43.

Google Scholar

[7] Wang Xuning, Xue Qunhu, Tian Xiaoli. Studuy on Properties of Ceramic Tiles Wet Grinding Slurry[J]. BULLETIN OF THE CHINESE CERAMIC SOCIETY. 2013, 32 (1): 94-99.

Google Scholar
