Experimental Study on Cryogenic Gas Atomization Jet Cooling Difficult-to-Cut Material

Abstract:

Based on pool film boiling, the model of boiling and vaporization to heat transfer is established When droplet jet into cutting zone to cool high temperature wall. Through the transient experiment of cryogenic gas atomization jet cooling high temperature nickel-base alloys and Titanium alloys surface with different water dose. The water dose achieving the best cooling effect is obtained at different temperature on surface of Nickel based alloys and TI-alloy. It is indicated that the water dose to the best cooling effect must be equivalent to the amount of water that materials can vaporize and participate in the phase change heat transfer under certain temperature. When achieving optimal cooling effect, the amount of droplets participating in phase change heat transfer to cool high temperature wall are the most , while comparing the cold air cooling effect and spraying cooling effect at low and high temperature. Result is that either low or high temperature, spraying cooling effect is superior than cold air cooling effect, but at a specific temperature, no lower the temperature of air, the better cooling effect, there is also an optimal air temperature values.

• Periodical: Advanced Materials Research (Volume 1095)
• Pages: 736-740
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1095.736
• Online since: March 2015
• Authors: Xiao Yan Guan*, Ai Sheng Wu
• Keywords: Cooling Experiment, Cryogenic Gas Atomization Jet Cooling, Difficult-to-Cut Material

References

[1] Ren Jialong, Discussion on Green Cooling Technique to cutting Cr12, Journal of East China Shipbuilding Institute. Natural Sci, 2001（3）：66-69（In Chinese ）.

[2] Zhao Wei, He Ning, Experimental Study on High Speed Milling of Ti-6Al-4V Alloy with Nitrogen-Oil-Mist JOURNAL OF NANJING UNIVERSITY OF AERONAUTICS & ASTRONAUTICS 2006, 38(5): 634-638.

[3] Liu L and Yao S C, Heat Transfer Analysis of Droplet Flow Impining on a Hot Surface, Heat Transfer 1982, 4, Hemisphere Publishing Co. 1982（6）.

DOI: 10.1615/ihtc7.3940

[4] Deb S, Yao S C, analysis on Film Boling Heat Transfer of Impacting Spray [J] . Int J Heat Mass Transfer 1989, 32(11): 2099～2112.

DOI: 10.1016/0017-9310(89)90117-8

[5] Xu Hongjun, Fu Yucan, SunFanghong．A basic study on heat affect mechanism and enhancing heat transfer in Contact Zone in efficient Grinding ．Science in China(Series E)，2002，32(3)：297-307（In Chinese ）.

[6] MeiGuohui MengHongji WuRongyang Analysis of spray cooling heat transfer coefficient on high temperature surface ENERGY FOR METALLURGICAL INDUSTRY Vo123, No. 6, 2004 18-23（In Chinese ）.
