Effect of Edge Masking on Residual Stress of Hot-Rolled Strip on Run-Out Table

Abstract:

A numerical model including thermal and microstructural model is established for precisely prediction of residual stress of hot-rolled strip on run-out table. Temperature and phase transformation fraction are coupled and formulated for the calculation of thermal and transformation expansion that could induce internal stress. Residual stress for hot-rolled strip before and after coiling are calculated using C++ program. Influence of edge masking on residual stress is analyzed. It is concluded that edge masking makes the strip flatness better after coiling.

• Periodical: Advanced Materials Research (Volume 1095)
• Pages: 732-735
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1095.732
• Online since: March 2015
• Authors: Xiao Hua Liu, Feng Dong, Dong Cheng Wang*
• Keywords: Edge Masking, Hot-Rolled Strip, Residual Stress, Run-Out Table

References

[1] H. Yoshida: Transaction ISIJ, Vol. 24(1984), p.212.

[2] Zhou Z, Thomson P F, Lam Y C, et al: J. Mater. Sci. Technol. Vol. 132(1)(2003), p.184.

[3] Wang X, Li F, Yang Q, et al: Applied Mathematical Modelling, Vol. 37(1)(2013): 586-609.

[4] Wang D, Dong F and Liu H: Advanced Materials Research Vols. 941-944 (2014) pp.2309-2312.

[5] Information on http: /www. paper. edu. cn/releasepaper/content/201101-1117.

[6] Han H N, Lee J K, Kim H J, et al: Journal of Materials Processing Technology, Vol. 128(1)(2002): 216-225.
