Pass Design and Finite Element Simulation for Trapezoidal Stainless Steel Sieve Bar

Abstract:

According to a company’s trapezoidal stainless steel sieve bar specification, 4-stands pass system and rolling program are proposed. To verify the pass system, 4-stands sieve bar three-dimensional finite element model is established and simulated by ANSYS/LS-DYNA. Parameters, such as metal flow law (metal longitudinal flow, metal lateral flow) and power parameters (stress, strain and rolling force), are obtained, and provide a reference for new product pass design optimization and improvement.

• Periodical: Advanced Materials Research (Volume 1095)
• Pages: 804-807
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1095.804
• Online since: March 2015
• Authors: Ya Qin Wang, Rui Liu, Lu Pan*
• Keywords: Finite Element, Metal Flow, Pass Design, Sieve Bar

References

[1] TANG Chang-song, XU Ken: China Pulp & Paper, vol. 29(2010), pp.50-52, in chinese.

[2] HUANG Qin-xue: Rolling Machine Design (Beijing, Metallurgical Industry Press 2007), in chinese.

[3] PAN Lu: Pass design and optimization of titanium alloy bar ( Taiyuan University of Science and Technology 2012), in chinese.

[4] PAN Lu, SHUAI Mei-rong, HUANG Qin-xue: Taiyuan University of Science and Technology, vol. 2(2012), pp.123-127, in chinese.

[5] SHUAI Mei-rong, HUANG Qin-xue, QIN Jian-ping: Rare Metal Materials and Engineering, vol. 6(2012), pp.952-957, in chinese.
