Simulation and Optimization of an Actuator

Abstract:

This paper presents a new methodology for the Reliability Based Particle Swarm Optimization with Simulated Annealing. The reliability analysis procedure couple traditional and modified first and second order reliability methods, in rectangular plates modelled by an Assumed Modes approach. Both reliability methods are applicable to the implicit limit state functions through numerical models, like those based on the Assumed Mode Method. In modified approaches, the algorithms are based on heuristic optimization methods such as Particle Swarm Optimization and Simulated Annealing Optimization. Numerical applications in static, dynamic and stability problems are used to illustrate the applicability and effectiveness of proposed methodology. The results of example show that the predicted reliability levels are accurate to evaluate simultaneously various implicit limit state functions with respect to static, dynamic and stability criterions.

• Periodical: Advanced Materials Research (Volume 1099)
• Pages: 110-119
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1099.110
• Online since: April 2015
• Authors: Norelislam El Hami*, Mhamed Itmi, A. El Hami
• Keywords: Dynamic, Global Optimization, Hybrid, PSO, SA, Structures, Vibration

References

[1] B. Radi, A. El Hami The study of the dynamic contact in ultrasonic motor  Applied Mathematical Modelling, Volume 34, Issue 12, December 2010, Pages 3767-3777(2010).

DOI: 10.1016/j.apm.2010.03.002

[2] A. Mohsine, G. Kharmanda and A. El Hami, Improved method as a robust toll for reliability-based design optimization, International Journal of Structural and Multidisciplinary Optimization, Springer, Vol. 32, N°. 3, September 2006, Pages 203-213(2006).

DOI: 10.1007/s00158-006-0013-2

[3] A. Mohsine, A. El Hami, A Robust Study of Reliability-Based Optimisation Methods under Eigen-frequency. International Journal of Computer Methods in Applied Mechanics and Engineering, Volume: 199, issues 17-20 March 2010, pages: 1006-1018 (2010).

DOI: 10.1016/j.cma.2009.11.012

[4] T. Moro, A. El Hami and A. El Moudni, Reliability analysis of a mechanical contact between deformable solids, International Journal of Probabilistic Engineering Mechanics, Volume 17, N°3, July 2002, Pages 227-232.

DOI: 10.1016/s0266-8920(02)00007-3

[5] El Hami and B. Radi, Some decomposition methods in the analysis of repetitive structures, International Journal Computers & Structures, Volume 58, N°5, March 1996, Pages 973-980(1996).

DOI: 10.1016/0045-7949(95)00206-v

[6] Kennedy J, Eberhart RC. Particle Swarm Optimization. ProceDen Hartog, J. P., 1956; Mechanical Vibrations; 1995; McGraw-Hill, New York, USA.

[7] B. Bochenek _ P. Fory_s, Structural optimization for post buckling behavior using particle swarms, Struct Multidisc Optim, 2006 pp.521-531.

DOI: 10.1007/s00158-006-0044-8

[8] J. Behnamian S.M. T Fatemi Ghomi, Development of a PSO-SA hybrid metaheuristic for a new comprehensive regression model to time-series forecasting, Expert Systems with Applications, 2010 pp.974-984.

DOI: 10.1016/j.eswa.2009.05.079

[9] Majid Bahrepour, Elham Mahdipour, Raman Cheloi, and Mahdi Yaghoobi, SUPER SAPSO: A New SA-Based PSO Algorithm, Applications of Soft Computing, 2009 pp.423-430.

DOI: 10.1007/978-3-540-89619-7_41

[10] D. Sarsri, L. Azrar, A. Jebbouri, A. El Hami Component mode synthesis and polynomial chaos expansions for stochastic frequency functions of large linear FE models. Computers & Structures, Volume 89, Issues 3-4, February 2011, Pages 346-356 (2011).

DOI: 10.1016/j.compstruc.2010.11.009

[11] A. Abo Al-kheer, A. El-Hami, M.G. Kharmanda, A.M. Mouazen, Reliability-based design for soil tillage machines Journal of Terramechanics, Volume 48, Issue 1, Pages 57-64 (2011).

DOI: 10.1016/j.jterra.2010.06.001

[12] A. El Hami, B. Radi and A. Cherouat, The frictional contact of the shaping of the composite fabric. International Journal of Mathematical and Computer Modelling. Vol 49, Issue 7-8 April 2009, pages 1337-1349(2009).

DOI: 10.1016/j.mcm.2008.09.016

[13] A. Cherouat, B. Radi and A. El Hami, The frictional contact of the shaping of the composite fabric. International journal Acta Mecanica, Volume 199, Numbers 1-4, pages 29-41(2009).

DOI: 10.1007/s00707-007-0566-1

[14] R. Bouyekhf, A. El Hami, A. El Moudni, Optimal Control of a particular class of singularity perturbed Non-linear Discrete-Time Systems. International Journal, IEEE, Transactions on Automatic Control, Vol 46, N°7, July 2001, pages1097-1101(2001).

DOI: 10.1109/9.935063

[15] El Hami, G, Lallement, P. Minotti and S. Cogan Methods that combine finite group theory with component mode synthesis in the analysis of repetitive structures. International Journal Computers & Structures, Volume 48, N° 6, Septembre 1993, Pages 975-982(1993).

DOI: 10.1016/0045-7949(93)90432-d
