Energy Loss Analysis and Magnetic Properties of Non-Oriented Electrical Steel Cut through Different Technologies

Abstract:

Non-oriented silicon iron (NO Fe-Si) alloys are soft magnetic materials used in the construction of medium and high power rotating machines. To obtain efficiency higher than 95%, it is necessary to promote a new design of their magnetic circuits and/or alternative cutting technologies. There were tested steel samples of fully processed non-oriented silicon iron (NO FeSi) grades, M400-65A and M800-65A, with an area of 300 × 30 mm². The magnetic properties were measured with a single strip tester in the range of frequency from 10 ÷ 200 Hz at 1 T peak magnetic polarization. The sheet cutting technologies, involved in this study, are mechanical, laser, water-jetting and electro-erosion.

You might also be interested in these eBooks

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 1105)

Pages:

83-87

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.1105.83

Citation:

Cite this paper

Online since:

May 2015

Authors:

Veronica Manescu Paltanea, Veronika Păltânea, Horia Gavrila

Keywords:

Coercive Field, Electro-Erosion, Energy Losses, Laser Cutting, Magnetic Permeability, Mechanical Cutting, Non-Oriented Silicon Iron, Water Cutting

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] IEA (International Energy Agency) statistics (2006), information on http: / www. iea. org/stats.

Google Scholar

[2] IEC (International Electrotechnical Commission) (2007).

Google Scholar

[3] IEC (2009), Guide for the Selection and Application of Energy Efficient Motors Including Variable Speed Applications (Draft), 60034-31, Geneva, information on http: / www. iec. ch.

Google Scholar

[4] Fausto Fiorillo, Measurement and Characterization of Magnetic Materials, Elsevier Academic Press, Amsterdam, (2004).

Google Scholar

[5] E. Gomez, J. Schneider, K. Verbeken, G. Pasquarela, Y. Houbaert, IEEE Trans. Magn. Vol 46 (2010), p.213.

Google Scholar

[6] G. Loisos, A.J. Moses, J. Mater. Process. Technol. Vol 161 (2005), p.151.

Google Scholar

[7] M. Emura, F. Landgraf, W. Ross, J. Barreta, J. Magn. Magn. Mater. Vol 254 (2003), p.358.

Google Scholar

[8] Y. Kurosaki, H. Mogi, H. Fujii, T. Kubota, M. Shiozaki, J. Magn. Magn. Mater. Vol 320 (2008), p.2474.

Google Scholar

[9] J. Peronczyk, J. Of KONES Powertrain and Transport Vol. 18 (2011), p.429.

Google Scholar

[10] C. Birtu, V. Avramescu, Nonconventional Technologies Review Vol. 16 (2012) p.40.

Google Scholar

[11] G. Paltanea, V. Paltanea, H. Gavrila, Rev. Roum. Sci. Techn. – Electrotechn. et Energ. 58 (2013) pp.53-62.

Google Scholar

[12] G. Bertotti: Hysteresis in Magnetism, Elsevier Academic Press, San Diego1998.

Google Scholar
