Prediction of Chip Morphology and Formation in High Speed Milling of Hardened Steels

Abstract:

A P20 steel are machined in the milling speed range of 200 to 942m/min. The morphology and formation of the chips are investigated at various speeds. The serrated chips with adiabatic shear band are observed at a high milling speed. The transition from continuous to serrated chip formation is favored by the increase in work material hardness and milling speed. The study assumes that the chip segmentation is only induced by adiabatic shear banding, without material failure in the primary shear zone. Based on adiabatic shear theory, using the JC and the power material constitutive equation, the modified material model which takes into a strain softening is developed for prediction of the serrated chip formation. Experimental measurements are compared with the simulation results.

• Periodical: Advanced Materials Research (Volumes 1120-1121)
• Pages: 1145-1152
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1120-1121.1145
• Online since: July 2015
• Authors: Jun Zhong Pang*, Xiao Bin Huang, Dou Dou Chang, Jie Pan
• Keywords: Chip Morphology, Finite Element Method (FEM), High Speed Milling, Modeling

References

[1] Elbestawi M A et al. High-Speed Milling of Dies and Molds in Their Hardened State[J]. Annals of the CIRP, 46(1)(1997): 57-62.

DOI: 10.1016/s0007-8506(07)60775-6

[2] Schulz H et al. Material Aspects of Chip Formation in HSC Machining[J]. Annals of the CIRP, 50(1)(2001): 45-48.

DOI: 10.1016/s0007-8506(07)62067-8

[3] Bäker M et al. A Finite Element Model of High Speed Metal Milling with Adiabatic Shearing[J]. Computers & Structures, 80(5, 6)(2002): 495-513.

DOI: 10.1016/s0045-7949(02)00023-8

[4] Rhim S H, Oh S I. Prediction of Serrated Chip Formation in Metal Milling Process with New Flow Stress Model for AISI 1045 Steel[J]. J. of Mater. Process. Techno. 171(2005): 417-422.

DOI: 10.1016/j.jmatprotec.2005.08.002

[5] Hortig C, Svendsen B. Simulation of Chip Formation during High-Speed Milling[J]. J. of Mater. Process. Techno., 186(2007): 66-76.

DOI: 10.1016/j.jmatprotec.2006.12.018

[6] Shivpuri H R. Prediction of Chip Morphology and Segmentation during the Machining of Titanium Alloys[J]. J. of Mater. Process. Techno., 150(2004): 124-133.

DOI: 10.1016/j.jmatprotec.2004.01.028

[7] Duan C Z, Wang M J, Pang J Z et al. Calculational Model of Shear Strain and Strain Rate within Shear Band in a Serrated Chip Formed during High Speed Machining[J]. J. of Mater. Process. Techno., 178(2006): 274-277.

DOI: 10.1016/j.jmatprotec.2006.04.008

[8] Sartkulvanich P et al. Determination of Flow Stress for Metal Milling Simulation-a Progress Report[J]. J. Mater. Proc. Techno., 146(2004): 61-71.

[9] Maekawa K, Ohhata H et al. Simulation Analysis of Machinability of Leaded Cr-Mo and Mn-B Structural Steels[J]. J. of Mater. Process. Techno., 62(1996): 363-369.

DOI: 10.1016/s0924-0136(96)02436-3
