Effects of Compaction and Sintering Temperature to the Alloyability of FeCrCu Powder Mixture

Abstract:

This paper presents the alloyability of FeCrCu powder compacts formed through warm powder compaction route. A lab-scale uni-axial die compaction rig was designed and fabricated which enabled the powder forming at elevated temperature. Iron powder ASC 100.29 was mechanically mixed with other alloying elements, i.e., copper (Cu) and chromium (Cr) as well as carbon (C) as additive for 60 minutes. Green samples were formed at 30°C (room temperature), 100°C, and 180°C through simultaneous upward and downward axial loadings. The defect-free green compacts were subsequently sintered in argon gas fired furnace at 900°C and 1000°C for 60 minutes at a rate of 5°C/minute. The alloyability of the sintered products was analyzed through XRD testing. The compressive strength of the sintered samples was also measured. The results revealed that FeCrCu alloy was formed at different intensity depended upon the forming and sintering temperature. The compressive strength was found to be highest for sample formed at 180°C and sintered at 1000°C.

• Periodical: Advanced Materials Research (Volume 1133)
• Pages: 264-268
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.1133.264
• Online since: January 2016
• Authors: Mujibur M. Rahman*, S.R. Yogaswerarow
• Keywords: Fe-Based Alloy, Sample Characterization, Sintering, Warm Compaction

References

[1] F.M. Lucas, B. Trindade, B.F.O. Costa, G. Le Caër, Mechanical alloying of Fe-Cu alloys from as-received and premilled elemental powder mixtures, Engineering Materials 230-232 (2002) 631-634.

DOI: 10.4028/www.scientific.net/kem.230-232.631

[2] H. Shi, D. Guob, Y. Ouyang, Structural evolution of mechanically alloyed nanocrystalline FeAl intermetallics, Journal of Alloys and Compounds 455 (2008) 207-209.

DOI: 10.1016/j.jallcom.2007.01.079

[3] D. Sharma, K. Chandra, P.S. Misra, Design and development of powder processed Fe-P based alloys, Materials and Design 32 (2011) 3198-3204.

DOI: 10.1016/j.matdes.2011.02.046

[4] S. Ziyuan, W. Deqing, D. Zhimin, Surface strengthening of pure copper by Ni-B coating, Applied Surface Science 221 (2004) 62-68.

DOI: 10.1016/s0169-4332(03)00753-0

[5] A. Gokce, F. Findik, A.O. Kurt, Microstuctural examination and properties of premixed Al-Cu-Mg powder metallurgy alloy, Material Characterization 62 (2011) 730-735.

DOI: 10.1016/j.matchar.2011.04.021

[6] J. Herman, G. Inden, G. Sauthoff, Deformation behaviour of iron-rich iron-aluminum alloys at high temperatures, Acta Materialia 51 (2003) 3233-3242.

DOI: 10.1016/s1359-6454(03)00144-7

[7] M.M. Rahman, S.S.M. Nor, An experimental investigation of metal powder compaction at elevated temperature, Mechanics of Materials 41 (2009) 553-560.

DOI: 10.1016/j.mechmat.2008.12.003

[8] M. M Rahman, S.S.M. Nor, H.Y. Rahman, Investigation on the effect of lubrication and forming parameters to the green compact generated from iron powder through warm forming route, Materials and Design 32 (2011) 447-452.

DOI: 10.1016/j.matdes.2010.06.013

[9] M.M. Rahman, A.K. Ariffin, S.S.M. Nor, H.Y. Rahman, Powder material parameters establishment through warm forming route, Materials and Design 32 (2011) 264-271.

DOI: 10.1016/j.matdes.2010.05.058
