Life Prediction of High Temperature Welded Component by Skeletal Point Rupture Stress

Abstract:

At the present time, as the steam conditions and capability of the supercritical power unit increasing, the unit reliability is an important factor for the unit efficiency. High temperature, thick walled pipes are widely used in power plants and chemical plants. In this paper, life of the welded joint was predicted by the methods of skeletal point (SP) rupture stress rupture stress, which was calculated by finite element method (FEM). For the life prediction of welded component, the continuum damage mechanics was employed too. The life prediction of the welded joint by SP rupture stress was compared with the life prediction by the method of continuum damage mechanics (CDM). The research results showed that the two predicted methods were consistent. So, it can be concluded that the SP rupture stress can be used for predicting life of the high temperature welded component. The SP rupture stress method was used conveniently for the structure of power plant or other high temperature components.

• Periodical: Advanced Materials Research (Volumes 118-120)
• Pages: 156-160
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.118-120.156
• Online since: June 2010
• Authors: Guo Dong Zhang, Yan Fen Zhao, Fei Xue, Zhao Xi Wang, Chang Yu Zhou
• Keywords: Finite Element Model (FEM), Life Prediction, Skeletal Point (SP) Rupture Stress, Welded Component

References

[1] G.D. Zhang, C.Y. Zhou. Trans China Weld Inst Vol. 28(2007), p.99.

[2] G.D. Zhang, C.Y. Zhou. Acta Metall Sin, Vol. 44(2008), p.848.

[3] T.H. Hyde, A.A. Becker, W. Sun, J.A. Williams. Int J Press Vessels Pip Vol. 83 (2006), p.853.

[4] T.H. Hyde, W. Sun. Int J Press Vessels Pip Vol. 79 (2002), p.331.

[5] T.H. Hyde, W. Sun, J.A. Williams. Int J Press Vessels Pip Vol. 2002, 79 (2002), p.799.

[6] S.T. Tu, in: High temperature structural integrity, edited by Science Press, Beijing (2003).

[7] C.Y. Zhou, G.D. Zhang. In: Proceedings of the 2009 ASME Pressure Vessel & Piping Conference, Prague, Czech Republic, (2009).

[8] G.D. Zhang, C.Y. Zhou. In: The 12th International Conference on Pressure Vessel and Technology, Jeju Island KOREA, (2009).

[9] G.D. Zhang, J.L. Xue, C.Y. Zhou. Trans China Weld Inst Vol. 29(2008), p.53.

[10] T.H. Hyde, A.A. Becker, W. Sun, J.A. Williams. Int J Press Vessels Pip Vol. 82 (2005), p.509.

[11] W. Sun, T.H. Hyde, A.A. Becker, J.A. Williams. Int J Press Vessels Pip Vol. 79(2002), P. 135.
