Bearing Parameter Optimization of a Compressor Rotor System Based on Orthogonal Experimental Design

Abstract:

A Low-pressure cylinder rotor of certain large centrifugal compressor units was studied by combing orthogonal experiments and finite element method. The effect of bearing parameters (length-diameter ratio, clearance ratio, dynamic viscosity of lubricating oil and preload) to bearing-rotor system stability and journal vibration was evaluated and optimum bearing parameters were determined. The significant and non-significant factors influencing on system stability and journal vibration were determined by variance analysis and F test. These conclusions will provide guidance to compressor rotor system design.

• Periodical: Advanced Materials Research (Volumes 118-120)
• Pages: 394-398
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.118-120.394
• Online since: June 2010
• Authors: Hui Ma, Yun Nan Teng, Ji Shuang Dai, Bang Chun Wen
• Keywords: Finite Element Model (FEM), Large-Scale Centrifugal Compressor, Orthogonal Experiment, Parameter Optimization

References

[1] A. Seireg and H. Ezzat: Trans. ASME Series F., Vol. 91(1969), p.516.

[2] R. B. Bhot: J. Trans. ASME Mech . De., Vol. 104(1982), p.339.

[3] L. E. Barrett: ASME Transactions. Journal of Mechanical Design, Vol. 105(1983), p.227.

[4] Hamit Saruhan: International Journal of mechanical sciences, Vol. 48 (2006), p.1341.

[5] R. Q. Liu and X. H. Wu: Journal of Aerospace Power, Vol. 11(1996), p.952 (in Chinese).

[6] J. Liu, W. Z. Zhang and Y. J. Zhou: Lubrication Engineering, Vol. 1(2006), p.57 (in Chinese).

[7] J. C. Wachel: NASA Conference publication 2250, Texas A&M University, (1982), p.1.

[8] J. C. Nicholas, E. J. Gunter and P. E. Allaire: ASLE, Vol. 22(1979), p.113.

[9] J. W. Lund: ASLE, Vol. 7(1964), p.342.

[10] G. F. Zhai: Proceedings of the CSEE, Vol. 23(2003), p.159.
