The Relationship between the Distribution Characteristics of Cutting Speed at the Contact-Point and the Surface Quality of Gear Teeth

Abstract:

In the paper, the vector expression of cutting speed on the contact-points has been obtained by the coordinate transformation. The cutting speed is the contact-point position function which is correlated with contact-line in the process of honing gear. It is diverse along the direction of the tooth depth, so the surface texture of workpiece gear has a visible difference from the top to the root of the tooth. It is showed in the results that the surface roughness value of same tooth has further increscent differences with the increasing honing speed, and the surface of tooth is in the same quality.

• Periodical: Advanced Materials Research (Volume 135)
• Pages: 128-133
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.135.128
• Online since: October 2010
• Authors: Guo Xing Liang, Ming Lv, Xiao Xu Gao
• Keywords: Cutting Speed, Honing Gear Machining, Roughness Value, Surface Quality

References

[1] E. Brinksmeier, A. Giwerzew: Wear Vol. 258 (2005), pp.62-69.

[2] H. K. Tönshoff, T. Friemuth, C. Marzenell: Annals of the CIRP. Vol. 49 (2000), pp.431-434.

DOI: 10.1016/s0007-8506(07)62982-5

[3] A. Ghosh, A.K. Chattopadhyay: Int. J. Machine Tools & Manufacture, Vol. 47 (2007), pp.1206-1213.

[4] T. W. Li: Principles Of Gear Engagement(II) (Shanghai Science and Technology Press, China 1984).

[5] Z. H. Pu, C. P. Sun, W. Q. Xia: Honing Gear Process (National Defence Industry Press, China 1965).
