An Experimental Study on the Kerf Characteristics of Silicon Cut with Micro Abrasive Air Jet

Abstract:

Micro abrasive air jet (MAAJ) cutting technology is being increasingly used in the precision machining of hard and brittle materials, due to its distinct advantages of negligible heat effect zone and small cutting force. In this paper, an experimental study on the kerf characteristics, especially for the effect of cutting parameters on the top edge definition, is presented. It shows that the top kerf edge is straight but not sharp. The top edge definition of the kerf improves with a decrease in the air pressure, while the effect of abrasive flow rate and nozzle traverse speed are hardly discernible. The optimum jet incidence angle for highest top edge definition of the kerf is 60°. The results of this paper may be useful for the cutting parameters optimization in the precision three-dimensional micro-structural machining.

• Periodical: Advanced Materials Research (Volume 135)
• Pages: 13-17
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.135.13
• Online since: October 2010
• Authors: Quan Lai Li, Chuan Zhen Huang, Jun Wang, Hong Tao Zhu, Zeng Wen Liu
• Keywords: Cutting, Kerf Characteristic, Micro Abrasive Air Jet, Top Kerf Edge Definition

References

[1] A. Ghobeity, T. Krajac, T. Burzynski, M. Papini and J. K. Spelt: Wear Vol. 264 (2008), p.185.

DOI: 10.1016/j.wear.2007.02.020

[2] P. J. Slikkerveer and F. H. Veld: Wear Vols. 233-235 (1999), p.377.

[3] H. Wensink and M. C. Elwenspoek: Sensors and Actuators, A: Physical Vol. 102 (2002), p.157.

[4] T. B. ten and P. J. Slikkerveer: Surv. on Math. Ind. Vol. 10 (2002), p.89.

[5] Q. L. Li, J. Wang and C. Z. Huang: J. Appl. Physics Vol. 104 (2008), 034903.

[6] Y. Ballout, J. A. Mathis and J. E. Talia: Wear Vol. 196 (1996), p.263.

[7] H. Z. Li, J. Wang and J. M. Fan: Int. J. Mach. Tools and Manufacture Vol. 49 (2009), p.850.

[8] P. H. Shipway and I. M. Hutchings: Wear Vols. 162-164 (1993), p.148.

[9] P. H. Shipway and I. M. Hutchings: Wear Vol. 174 (1994), p.169.

[10] A. N. Stevenson and I. M. Hutchings: Wear Vol. 189 (1995), p.66 50µ m 50µm 50µm.
