Applying Element-Free Galerkin Method to Simulate Die Forging Problems

Abstract:

The analysis for die forging forming problems with finite element method can lose considerable accuracy due to severely distortional meshes. The element-free Galerkin method is suitable for large deformation analysis and provides a higher rate of convergence than that of the conventional finite element methods. A rigid-plastic meshless method based on the element-free Galerkin method has been applied to die forging problems. The arc-tangent friction model is used to handle frictional contact and the penalty method is applied to impose the volumetric incompressibility conditions. By dividing all integration points set into the point subset of the rigid zones and the point subset of the plastic zones, nonsmoothness of the rigid-plastic constitutive relation can be eliminated. A die forging example has been analyzed to demonstrate the performance of the method.

• Periodical: Advanced Materials Research (Volumes 139-141)
• Pages: 1174-1177
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.139-141.1174
• Online since: October 2010
• Authors: Di Li, Jia Chuan Xu, Wen Qian Kang
• Keywords: Die Forging, EFG Method, Moving Least Square Method, Rigid-Plastic

References

[1] T. Belytschko, Y. Krongauz and D. Organ et al., Computer Methods in Applied Mechanics and Engineering, Vol. 139 (1996), p.3.

[2] G. Zhao, W. Wang, Y. Luan. Chinese Journal of Mechanical Engineering, Vol. 40(2004) , No. 11, p.13.

[3] J. Chen, H. Wang, Computer Methods in Applied Mechanics and Engineering, Vol. 187(2000), p.441.

[4] Poluhin PI: Plastic Forming Resistance of Metals and Alloys(China Machine Press, China 1984). Fig. 4 Maximum diameter and height at different displacement.
