The Research of the Ultrasonic Heat Meter Adopting a Through Structure

Abstract:

The pattern of using the household billing to promote heating energy savings has become a focus discussion in the current national energy conservation. However, based on the fact that there is so much impurities in domestic heating system pipes, the research work of the flow meter adapting to our nation has been carried out slowly. In this paper, we report a research of a V-type installation flow meter. The meter uses the through V-type arrangement ultrasonic sensor- pair. It measures the flow by the time difference method and the entrance and exit temperature of the unit by platinum resistance-pair temperature sensors. It calculates the heat consumption by k coefficient method. The flow meter has been carried on the online testing in a district of Beijing in 2009.

• Periodical: Advanced Materials Research (Volumes 139-141)
• Pages: 2287-2290
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.139-141.2287
• Online since: October 2010
• Authors: Shi Liang Nie, Tokio Sugi, Bin Liao
• Keywords: A through Structure, Online Testing, Ultrasonic Heat Meter

References

[1] Baoxing Qiu. Implement scientific concept of development-Further accelerate the reform of urban heating system[Z]. Shenyang. National Heat Reform Working Conference, 2006, 8.

[2] Ministry of Construction P.R. China. CJ128-2007, Urban construction profession standard Heat meter. Beijing. Standards Press of China, (2008).

[3] State General Administration of the People's Republic of China for Quality Supervision and Inspection and Quarantine. JJG225-2007, Heat meter testing procedures. Beijing: China Metrology Publishing House, (2002).

[4] The building energy conservation Ninth Five-year, plan and 2010 plan in Ministry of Construction. Beijing. Ministry of Construction P.R. China, (1995).

[5] European Standard, EN1434: 1997, heat meters, (1997).

[6] Zhijun Jin, Ping Qiu. The analysis and determination of heat exchange coefficient in the measurement of heat meter. Modern metrological testing technology, 2001(2): 53~54.
