Harmonic Response Analyses of Three Knife-Shape-Tooth Star-Wheel Loading Mechanism

Abstract:

In order to research dynamic natures of a three knife-shape-tooth star-wheel loading mechanism, a mechanical model and a solid model of the star-wheel loading mechanism are established by means of updated-Lagrange and ANSYS software in the paper, equivalent stress clouds and displacement responding curves of the star-wheel at different excitation frequencies are obtained through harmonic response analyses. Model analysis shown that the star-wheel loading mechanism doesn’t take place resonance when the excitation frequency locates between 1.8 and 2.4 Hz, and the star-wheel works stability when the rotation speed is from 36 r/min to 48 r/min. These conclusions from study lay a theoretical foundation for improving the design of a three knife-shape-tooth star-wheel loading mechanism and make better its dynamic behavior.

• Periodical: Advanced Materials Research (Volumes 139-141)
• Pages: 2322-2325
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.139-141.2322
• Online since: October 2010
• Authors: Xiao Huo Li, Yong Dong Sha, Ji Quan Yao, Chun Hua Liu
• Keywords: Harmonic Response, Knife-Shape-Tooth, Loading Mechanism, Star-Wheel

References

[1] X.C. Xie and X.H. Li: Mining Machinery and Equipment(China University of Mining, China 2007).

[2] X.H. Li and C.H. Liu: Journal of Liaoning Technical University (Natural Science Edition), (2007) No. 11, pp.182-184.

[3] X.H. Li and X.D. Liang. Journal of Heilongjiang Institute of Technology(2007) No. 17, p.102104.

[4] S.P. Wang: Coal Science and Technology(2005) No. 33, pp.46-48.

[5] X.H. Li and C.H. Liu: Colliery Mechanical& Electrical technology(2008) No. 1, p.30, 33.

[6] C.H. Liu: Property study of star-wheel loading mechanism on roadgeader(MS., Liaoning Engineering Technology University, China 2007).
