Inner Leakage Fault Diagnosis of Hydraulic Cylinder Using Wavelet Energy

Abstract:

Inner leakage of hydraulic cylinder is a very serious failure in the hydraulic system and it can lead to many problems.A important fault diagnosis way is to detect the pressure signal.But the pressure signal is seriously influenced by pressure fluctuation and other noises.It is difficult to extract features from pressure singal. Aiming at the difficulty in extracting feature from pressure singal in fault diagnosis for leakage of hydraulic cylinder,a fault diagnosis approch based on monitoring preesure singal and wavelet energy is proposed in this article.According to the method, the enegry of different frequency bands after wavelet decomposition costitutes the eigenvectors at first, then these eigenvectors are input into BP network to identify faults. The experimental results show that three modes of no leakage, slighter leakage and severe leakage were correctly identified.This approach can be used in the leakage fault diagnosis of hydraulic cylinder.

• Periodical: Advanced Materials Research (Volumes 139-141)
• Pages: 2517-2521
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.139-141.2517
• Online since: October 2010
• Authors: Hong Bin Tang, Yun Xin Wu, Chang Xun Ma
• Keywords: BP Network, Fault Diagnosis, Inner Leakage of Hydraulic Cylinder, Wavelet Energy

References

[1] TOTTN G E. Handbook of hydraulic fluid technology[M]. Marcel Dekker, (2000).

[2] An Liang; Sepehri Nariman. Leakage fault detection in hydraulic actuators subject to unknown external loading[J]. International Journal of Fluid Power, 2008, 9(2): 15-25.

DOI: 10.1080/14399776.2008.10781301

[3] Wang Changting, Robert X Gao. Wavelet transform with spectral post-processing for enhanced feature extraction[J]. IEEE Transactions on Instrumentation and Measurement, 2003, 52(4): 1296-1301.

DOI: 10.1109/tim.2003.816807

[4] Zhimin Du, Xinqiao Jin, Yunyu Yang. Fault diagnosis for temperture, flow rate and pressure sensors in VAV systems using wavelet neural network[J]. Applied Energy, 2009(86): 1624-1631.

DOI: 10.1016/j.apenergy.2009.01.015

[5] NARENDRA K S, PARTHASARATHY K. Identification and control of dynamical systems using neural networks[J]. IEEE Trans. on Neural Networks, 1990, 1(1): 4-27.

DOI: 10.1109/72.80202

[6] Wang Xuanyin, Li Xiaoxiao, Li Fushang. Analysis on oscillation in electro-hydraulic regulating system of steam turbine and fault diagnosis based on PSOBP[J]. Expert Systems with Applications, 2010, 37: 3887-3892.

DOI: 10.1016/j.eswa.2009.11.029

[7] Teodor Marcu, Birgit K, Reinhard S. Design of fault detection for a hydraulic looper using dynamic neural networks[J]. Control Eng Pract 2008, 16(2): 192-213.

DOI: 10.1016/j.conengprac.2006.11.017
