The Changing Law of Tooth Bending Stress for Herringbone Gears with High Contact Ratio

Abstract:

From the principle of generating method, the precise model of an involute herringbone gear was built. The accurate load distributions of herringbone gear were obtained in different meshing positions in linear programming method. Then the changing course of root bending stress along with the variation of meshing position was gained. The calculation process realized the automatic definition of loads and boundary conditions, and found out the value and the position when the tooth root has maximum bending stress. The results showed that the maximum stress usually appears near the position when the tooth bears maximum load. Be different from spur gears, the maximum stress of herringbone gears will possibly appear in the section where more teeth couples are engaged. The analysis can effectively provide reference for checking tooth bending strength of herringbone gears.

You might also be interested in these eBooks

Manufacturing Engineering and Automation I

View Preview

Info:

Periodical:

Advanced Materials Research (Volumes 139-141)

Pages:

965-969

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.139-141.965

Citation:

Cite this paper

Online since:

October 2010

Authors:

Le Hao Chang, Geng Liu

Keywords:

Herringbone Gear, Load Distribution, Tooth Bending Stress

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] V. Ramamurti and M. Anada: Computers and Structures, Vol. 29 (1988) No. 5, pp.832-843.

Google Scholar

[2] S. ODA, T. Koide and K. Umezawa: Bulletin of JSME, Vol. 29 (1986) No. 255, pp.3149-3156.

DOI: 10.1299/jsme1958.29.3149

Google Scholar

[3] T. Jabbour and G. Asmar: Mech Mach Theory, Vol. 44 (2009) No. 12, pp.2236-2247.

Google Scholar

[4] S.F. Gu, X.M. Lian and N.G. Ding: Mechanical Science and Technology, Vol. 15 (1996) No. 2, pp.167-171, (In Chinese).

Google Scholar

[5] J.H. Bao, Y.H. Zhang and X.L. Hu: Mechanical Transmission, Vol. 25 (2005), No. 1, pp.19-22, (In Chinese).

Google Scholar

[6] J.Z. Zhu: The Choice of Involute Gear Modification Coefficient, (People's Education Press, China, 1982), pp.39-48.

Google Scholar

[7] Z.M. Liu and G. Liu: Computer Simulation, Vol. 26 (2009), No. 2, pp.298-300, (In Chinese).

Google Scholar

[8] Z.H. Bu and G. Liu: Mechanical Science and Technology, Vol. 27 (2008), No. 11, pp.1365-1368, (In Chinese).

Google Scholar
