A Method to Center Extraction of Reference Point Algorithm in Reverse Engineering

Abstract:

In reverse engineering, in order to get the entire point data of the object surface, which must be merged from point data cloud obtained from different angles. And in order to acquire exactly merge effect, a method to stick reference points on object surface to acquire base point. Thus, the precision of center extraction of reference point affect the merge result. Firstly a new method to center extraction of reference point is presented based on the characteristics to the images in reverse engineering in this paper. And the new method is that the region recognition algorithm combining to least squares algorithm. Secondly, in order to improve the computational efficiency, the modified sequential algorithm is applied to optimize the region recognition. Lastly, the availability and accuracy to the new method are proved by the experiment.

• Periodical: Advanced Materials Research (Volume 142)
• Pages: 214-218
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.142.214
• Online since: October 2010
• Authors: Xiang Qian Che, Jun Ting Cheng, Sheng Bing Xiao, Jia Jun Ma
• Keywords: Center Extraction, Reference Point, Reverse Engineering (RE), Sequential Algorithm

References

[1] Chitra Dorai, Member. Pattern Analysis and Machine Intelligence, Vol. 20(1998) No. 1, pp: 83-89.

[2] Richard P. IEEE Trans on Image Processing, Vol. 4(1995) No. 3, pp: 554-568.

[3] Jodoin M, Mignotte M. Proc of the 11th IEEE International Conference on Image Processing. Singapore, ingapore, (2004), pp: 2591-2594.

[4] Cooper, G.R.J. Computers & Geosciensces, Vol. 32 (2006) No. 10, pp: 1592-1599.

[5] Canny J. IEEE Trans on Pattern Analysis and Machine Inteligence, Vol. 8 (1986) No. 6, pp: 679-698.
