Effect of Nozzle Layout Parameters on the Controlled Cooling of Flat Steel

Abstract:

The three dimensional unsteady cooling process of flat steel is simulated by the numerical simulation calculation method of Finite Element Coupling Field. Then, the influential rules, which about layout parameters of the controlled cooling nozzle such as the distance and number of nozzle rows on the cooling effect, are analyzed separately. The results show that the distance of nozzle has a little effect on cooling rate. Relatively the number of nozzle rows affects cooling rate of flat steel greatly. Different layout parameters of the controlled cooling nozzle will be used by considering different factors. The numerical simulation results provide references for the layout of steel nozzle and controlled cooling device.

• Periodical: Advanced Materials Research (Volume 145)
• Pages: 326-331
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.145.326
• Online since: October 2010
• Authors: Shao Jun Zhang, Dong Mei Zhu, Guo Yong Liu
• Keywords: Controlled Cooling, Flat Steel, Nozzle, Numerical Simulation

References

[1] G.G. Feng: SiChuan Metallurgy, (1996)No. 1, p.73. (In Chinese).

[2] L.B. Wang: Study of Rod Controlled Cooling Equipment Structure and Parameters (MS., University of Science and Technology Beijing, China 2009), p.18. (In Chinese).

[3] J.D. Sun and S.X. Ding: Steel and Iron Research, (2005)No. 2, p.48. (In Chinese).

[4] D.L. Song: Metal Heat Treatment, (2006)No. 10, p.76. (In Chinese).

[5] Z.Z. Chen. Mould Steel Handbook (Metallurgical Industry Press, China 2002). (In Chinese).

[6] F.L. Wang: Study of Numerical Simulation and Controlled Cooling Modal in Plate Controlled Cooling Process (Ph.D., University of Science and TechnologyBeijing, China 2003), p.43. (In Chinese).
