Ultimate Strength Analysis of Ship Hulls of Continuous Basalt Fiber Composite Materials

Abstract:

Based on effective composite material failure criteria and property limited degradation model, axial compressive ultimate strength of composite laminated stiffened panels are analyzed by nonlinear laminated degenerated 3D finite element analysis, which is based on incremental continuum-based updated Lagrangian formulation. Comparison between analytical solutions and test results in this article indicates that this article provides an effective and practical method to evaluate the axial compressive ultimate strength of composite laminated stiffened panels. Using this method, ultimate strength of hull girders made of continuous basalt fiber composite materials are analyzed . Comparing the results，it can be seen that the ship hull in basalt fiber composite materials has equivalent longitudinal ultimate strength to S-2 glass fiber composite materials, basalt fiber composite material could replace the S-2 glass fiber composite materials used in shipbuilding engineering. The gist for building ship with basalt fiber composite materials was provided by this paper.

• Periodical: Advanced Materials Research (Volumes 150-151)
• Pages: 736-740
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.150-151.736
• Online since: October 2010
• Authors: Wei Zhang, Wen Yong Tang, Ying Chao Pu, Sheng Kun Zhang
• Keywords: Basalt Fiber Composite Material, Failure Criterion, Nonlinear Finite Element, Ultimate Strength of Ship Hull

References

[1] Vanvoom B, Smith H G, Sinke R J, et al. Composites PartA, 2001, 32: 1271.

[2] Quanying Run. Thermal mechanism and materials of preparation of basalt fibers[D]. Harbin: Harbin Institute of Technology, (2000).

[3] Yihua Cui. Journal of Textile Research, 2005, 26(5) : 57260.

[4] Er-Gai Xie, Zhong-Ying Li. Fiber Composites, 2003 , 17 (3) : 17220.

[5] Ships & Yachts, 2008, 04.

[6] Petit P H, Waddoups M E. Journal of Composite Materials, 1969, 3: 2-19.

[7] Smith C S, Dow R S. Compressive strength of longitudinally stiffened GRP panels[C]. Proceedings 3rd International Conference on Composite Structures, Paisley, 1985: 468-490.

DOI: 10.1007/978-94-009-4952-2_33

[8] Smith C S, Dow R S. Interactive buckling effects in stiffened FRP panels[C]. Proceedings 4rd International Conference on Composite Structures, Paisley, 1987, 1: 122-137.

DOI: 10.1007/978-94-009-3455-9_9

[9] Zhulin Zhou. Applied Mathematics and Mechanics, 1998, 19(4): 365-371.

[10] Khan, Shah M Z, Simpson G. Materials Letters, 2000, 45(3): 167-174.

[11] Kong C W, Lee I C, Kim C G, et al. Composite Structures, 1998, 42: 13-21.

[12] Ming-Fa Cao. Characteristic of the material, design and construction of FRP mine-hunting boat hull [C]. Annual Meeting TECHNOLOGY of China Shipbuilding Institute of Technology Materials Engineering Academic Committee, (1988).

[13] Ming-Fa Cao, Jun Chen. SHIP & BOAT, 1994, 04: 21-26.

[14] Jing Zhu, Xin-Sen Lu, Ming-Fa Cao, et al. Ship Engineering, 1996, 01: 26-30.

[15] Jing Zhu, Jun Guo, Ming-Fa Cao. Shipbuilding of China, 1996, 04: 32-40.

[16] Nianzhong Chen. Composite Structures, Volume 77, Issue 1, January 2007, Pages 36-44.

[17] Tan SC. J Comp Mater 1991(25): 566-77.
