Research about Online Inspection System for the Assembly Quality of Automobile Gearbox Sliding Bracket

Abstract:

Gearbox sliding bracket is an important component of Automobile Gearbox. Because it has many parts which have little difference in shape and size, it is very easy to make mistake in assembly parts of this component. Due to mass production, it is high time to develop an online inspection system for the aseembly quality. Analysis the assembly characteristic of the component, this paper develop an online inspection system which is mainly composed of a central control system(CCS) and a sensor. Under the command of the CCS, the sensor is able to automatically inspect the component’s parts of which are wrong assmbly, reverse assembly and missing assmbly. Also the sensor can send the inspection information to the CCS. Subsequently, the CCS judges the information and dispalys the judgment result in time. At the same time, through the network, it is able to send the assembly quality information to the enterprise quality management system, such as the eligible amount, the reject amount, the qualification rate. This online automatic inspection system has run in good condition since it was officially put into operation at 2007 and its accuracy comes up to 100%.

• Periodical: Advanced Materials Research (Volumes 152-153)
• Pages: 368-371
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.152-153.368
• Online since: October 2010
• Authors: Chun Dong Zhu, Fei Guo, Bo Wei
• Keywords: Assembly Quality, Automatic Inspection, Sensor, Sliding Bracket

References

[1] J.G. Lin, Y. Wei and H. b. Yang: Modular Machine tool & Automatic Marnufacturing Technique, (2008) No. 3, pp.68-70. (In Chinese).

[2] S.T. Shao: Development & Study of Measure System of Fork Assembly Machine[D], Wuhan University of Technology. (2007) pp.6-7, 25. (In Chinese).

[3] W.H. Yu: a Study on the Computer Test System for Forked Parts Assembly Based on MCGS[D], Wuhan University of Technology. (2007) p.1. (In Chinese).

[4] J. Zhu and S. t. Shao: Manufacturing and Automation, Vol. 31(2009) No. 2, pp.92-94. (In Chinese).

[5] D.M. Chen, X.Y. Li, J.B. Hu and S.H. Yuan: transactions of beijing institute of technology, Vol. 26(2006) No. 10, pp.855-860. (In Chinese).

[6] M.K. Osman, M.Y. Mashor and M.R. Arshad: Proceedings of the 2004 IEEE Conference on Cybernetics and Intelligent Systems Singapore, (2004), pp.1011-1015.

[7] T.B. Shen: Online Automatic Detection Technology and System of Automotive Final Drive[D], Zhejiang University. (2006). P. 8 (In Chinese).

[8] J. Chen and H. Huang: Sensors and Detection Technology[M], Higher Education Press. (2002) p.8. (In Chinese).
