Numerical Analysis of the Multi-Point Stretch Forming Process of Aircraft Outer Skin Part

Abstract:

As a flexible manufacturing technique, Multi-point stretch forming (MPSF) is a suitable method for forming aircraft outer skin part. The traditional solid stretching die is replaced by the discrete multi-point die (MPSD), and the sheet metal is stretch-formed over the MPSD generated by serial adjusting mode or parallel adjusting mode. The MPSF can be used to form the parts of different shape and reduce the cost and leading time of stretching die fabrication for aircraft outer skin part. A series of numerical simulations on typical MPSF processes of aircraft outer skin part were carried out. The thickness of elastic cushion and free length are important factors to influence on the stretch forming results of stretch-formed parts. The numerical simulation results show that the thicker the elastic cushion is, the more valid the dimple will be suppressed .The longer the free length is, the easier the wrinkle will be brought.

• Periodical: Advanced Materials Research (Volumes 154-155)
• Pages: 1068-1072
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.154-155.1068
• Online since: October 2010
• Authors: Shao Hui Wang, Zhong Yi Cai, Ming Zhe Li, Ying Wu Lan
• Keywords: Dimples, Free Length, Multi-Point Stretch-Forming, Wrinkling

References

[1] Z.H. Zhou, Z.Y. Cai and M.Z. Li: Journal of Jilin University (Engineering and Technology Edition) Vol. 19(3) (2005), pp.287-291 (in Chinese).

[2] N. Nakajima: J Japen Soc Mesh Vol. 72(603)(1998), pp.498-506.

[3] D.E. Hardt and D.C. Grossard: Joint Automatic Control Conference(San Francisco, California USA, August, 1980).

[4] D. E Hardt, B. A Olsen and B.T. Allison et al: Proc. 9th NAMRC, (1981), pp.140-144.

[5] D.F. Walczyk, D.E. Hardt : Journal of Manufacturing Systems Vol. 17(6)(1998), pp.436-454.

[6] D. F. Walczyk, J. Lakshmikanthan and D.R. Kirt: Journal of Manufacturing Systems Vol. 17(4) (1998), pp.287-296.

[7] J.M. Papazian: Mechanical Engineering, Vol. 124(2) (2002), pp.52-55.

[8] M.Z. Li, Z.Y. Cai and C.G. Liu, et al: Proceedings of the 8th International Conference on Technology of Plasticity( Edizioni Progetto Padova, Verona, Italy October 9-13, 2005).

[9] H.A. Al-Qureshi: Journal of Materials Processing Technology Vol. 125-126(2002), p.751–755.

[10] Z.Y. Cai, M.Z. Li and W.Z. Fu: Forging & Stamping Technology Vol. 1 (2003), pp.16-19.

[11] M.Z. Li, Y.S. Pei and J.L. Xu: Material Science and Technology Vol. 1(4) (1998), pp.379-382.
