Development and Experimental Investigation of a High Speed Grinding Spindle Equipped with Fully-Ceramic Bearings and Ceramic Shaft

Abstract:

Trend of the high-speed and high efficiency machining has pushed the continuous demand of higher spindle speed and power for the machining center application. However, Conventional steel spindles are not appropriate for high speed operation because of their high rotational inertia and low damping ratio. Moreover, heat generation and dynamic loading caused by high speed rotation have been obstacles for increasing the speed limit in many conventional steel spindles applications. Apart from optimizing lubrication, the application of new materials is an interesting alternative to increase the boundary speed and life-span of roller bearings for machine-tool spindles. In this study, a high speed grinding motorized spindle equipped with hot isostatically pressed silicon nitride (HIPSN) fully-ceramic ball bearings without inner rings and yttria partially stabilized tetragonal zirconia polycrystal (Y-TZP) ceramic spindle shaft was designed for higher speed, rigidity, precision and longer operating life. Furthermore, the characteristics of ceramic motorized spindle, such as temperature increase, vibration, power, rigidity, noise and so on, were investigated by the experimentation. The results show that the ceramic motorized spindles have good behaviors under low load, high speed grinding conditions.

• Periodical: Advanced Materials Research (Volumes 156-157)
• Pages: 1366-1371
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.156-157.1366
• Online since: October 2010
• Authors: Song Hua Li, Yu Hou Wu, Li Xiu Zhang
• Keywords: Ceramic Motorized Spindle, Grinding, Rigidity, Temperature Increase, Vibration

References

[1] B. Bossmanns and J.F. Tu: International Journal of Machine Tools & Manufacture, Vol. 39 (1999), pp.1345-1366.

[2] O. Maeda, Y. Cao and Y. Altintas: International Journal of Machine Tools Manufacture, Vol. 45 (2005), pp.537-548.

DOI: 10.1016/j.ijmachtools.2004.08.021

[3] S.H. Yeo, K. Ramesh, Z.W. Zhong: International Journal of Machine Tools & Manufacture, Vol. 42 (2002), pp.815-823.

[4] Y.H. Wu: Technology of NC Machine Tool Motorized Spindle (China Mechanical Industry Press, China 2006) (In Chinese).

[5] K.G. Bang and D.G. Lee: Composite Structures, Vol. 55 (2002), pp.247-259.

[6] Y.H. Wu: HIPSN Ceramic Ball Bearing (Liaoning Science and Technology Press, China 2003) (In Chinese).

[7] S.H. Li and Y.H. Wu: Key Engineering Materials, Vol. 359-360 (2008), pp.108-111.

[8] C.H. Wu and Y.T. Kung: Precision Engineering, Vol. 128 (2004), pp.232-238.

[9] M. Weck, A. Koch: Annals of the CIRP, Vol. 42 /1 (1993), pp.445-448.

[10] M. Weck, G. Spachtholz: Annals of the CIRP, Vol. 52/1 (2003), pp.311-316.

[11] C. Brecher, G. Spachtholz, F. Paepenmüller: Annals of the CIRP, Vol. 56/1(2007), pp.395-399.

DOI: 10.1016/j.cirp.2007.05.092

[12] S.H. Li and Y.H. Wu: Applied Mechanics and Materials, 2010. (Accepted).

[13] S. Katsuo, K. Tsunemoto, et al.: JSPE 63 (4) (1997), pp.560-564.
