The Product Surface Remote Detection Method Based on the Single Laser Pulse Echo

Abstract:

Laser detecting technology can be utilized to the product surface detection for finding the surface deficiency. However, the improving resolving power of laser detecting system is limited by the laser footprint size on the product surface. Employing only echo delay and intensity information, the information of the surface inside the footprint is difficult to be obtained for the echo signal of the objects maybe is submerged by each other. Under the remote laser detecting, the serious loss of image quality may occur because of the large footprint. The product surface detection method based on the single laser return waveform was studied and the provided to get the objects information inside the laser footprint. Firstly, the basis laser echo signal model of the objects inside the footprint was built. On the basis, the decomposition algorithm was provided which can decompose a laser return waveform into a series of components assuming that each component corresponding to a sub-object inside the laser footprint. After the primary sub-target return waveforms was obtained, however, there still exists some small sub-objects inside the laser footprint whose return signal is hardly to be extracted because they are submerged by the neighborhood sub-objects return signal. The subtracting algorithm between the whole return waveform and the components waveform provides the way to get the submerged return waveforms of sub-target. So, the information of sub-objects inside the laser footprint would be obtained. In the end, the actual laser return data of the product surface was analyzed employing the method to get the range position information of the sub-objects inside the laser footprint, which verifies the method validity.

• Periodical: Advanced Materials Research (Volumes 156-157)
• Pages: 481-487
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.156-157.481
• Online since: October 2010
• Authors: Qun Zhan, Nan Sheng
• Keywords: Data Processing, Laser Detecting, Product Surface Detection, Single Laser Return Waveform Analysis

References

[1] HA RDING D J, BUFTON J L, FRAWLEY J J. Satellite laser altimetry of terrestrial topography: vertical accuracy as a function of surface slope, roughness, and cloud cover[J]. IEEE Transaction on Geoscience and Remote Sensing, 1994, 32(2): 329-337.

DOI: 10.1109/36.295048

[2] HU Yi-hua, SHU Rong, XUE Yong-qi. Improving the qualification of georeferenced image in the airborne scanning laser ranging-imaging sensor[C]/ Proceedings of SPIE, Infrared Technology and Applications XXVI, 2000, 4130: 13-20.

DOI: 10.1117/12.409864

[3] GARDNER C S. Ranging performance of satellite laser altimeters[J]. IEEE Transaction on Geoscience and Remote Sensing, 1992, 30(5): 1061-1072.

DOI: 10.1109/36.175341

[4] HU Yi-hua, WEI Qing-nong, Zhang Li-min. An analysis of the ground resolution of the airborne scanning laser rangefind[J]. Infrared and Laser Engineering, 1998, 27(2): 37-39.

[5] BUFTON J L. Laser altimetry measurements from aircraft and spacecraft[J]. Proceedings of the IEEE, 1989, 77(3): 463-477.

DOI: 10.1109/5.24131

[6] HU Yi-hua, WEI Qing-nong, Liu Jian-guo, et al. An analysis of the characteristics of the return pulse in airborne laser beam scanning[J]. Applied Laser, 1997, 17(3): 109-111.

[7] ZHAO Nan-xiang, Hu Yi-hua. Study on characterisitics of terrain objects with laser echo identities of earth observation[J]. Chinese Journal of Quantum Electronics, 2003, 20(5): 566-569.

[8] KRAWCZYR R, GORETTA O, KASSIGHIAN A. Temporal pulse spreading of a return lidar singal[J]. Applied Optics, 1993, 32(33): 6784-6788.

DOI: 10.1364/ao.32.006784

[9] ZHAO Nan-xiang, Hu Yi-hua. Relation of laser remote imaging singal and object detail identities[J]. Infrared and Laser Engineering, 2006, 35(2): 226-229.

[10] ZHAO Nan-xiang, Hu Yi-hua. Synthesizing algorithm for laser remote sensing imaging multi-signal[J]. Infrared and Laser Engineering, 2008, 37(4): 667-670.

[11] HOFTON M A, MINSTER J B, BLAIR J B. Decomposition of laser altimeter waveforms[J]. IEEE Transaction on Geoscience and Remote Sensing, 2000, 38(4): 1989-1996. Acknowledgements：The paper is supported by the National Natural Science Foundation of China (No. 60672154).

DOI: 10.1109/36.851780
