The SEM and EDS Energy Spectrum Analysis of a Beach Placer

Abstract:

In order to study the phase of Fe and Ti in a beach placer , different methods such as the X-ray diffraction analysis, chemical analysis, scanning electron microscopic , electron probe microanalysis are used to study the characteristics of the beach placer . The research results show the major metallic mineral in the beach placer is titanic magnetite, EDS and energy spectrum map features of which indicate that the vast majority of titanic magnetite contain a certain amount of Ti , the two elements of Fe and Ti take on closely symbiosis and distribute more evenly in titanic magnetite. The Ti exists in the Magnetite lattice in form of isomorphism. The theoretical highest grade of Fe and Ti in the separated Magnetic concentrate are 66.02per cent and 4.86 per cent respectively. In addition, the beach placer contains a small quantity of Ilmenite which is hysterogenic and exists in the form of fine solid solution separation structure in the titanic magnetite

• Periodical: Advanced Materials Research (Volume 158)
• Pages: 273-280
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.158.273
• Online since: November 2010
• Authors: Jun Qiu, Xian Jun Lu, Ping Chen, Shu Gang Hu, Gui Fang Wang
• Keywords: Beach Placer, Ilmenite, Isomorphism, Titanic Magnetite

References

[1] J. Qiu, X. Lu, P. Chen , et al: Technique of Iron Ore Separation( Chemical Industry Press, Beijing, China, 2009).

[2] J.K. Kima, H.S. Oha, C.W. Jo , et al: Chemical Engineering Research and Design., Cherd-364(2009),P. 1-7.

[3] J. Qiu, X . Lu ，Q. J LI: Journal of Mineralogy and Petrology, Vol. 2 (2009), P. 12-17.

[4] Y. Sun, C. Han: Marine geology and quaternary geology, Vol. 19 (1999), P. 117-121.

[5] L. Zhou. Process Mineralogy. (Metallurgical Industry Press, Beijing, China, 2002).

[6] Department of Geology Peking University. Optical Mineralogy. (Geological Publishing House, Beijing, China, 1988).
