Gate-Length Biasing Technique of Complementary Pass-Transistor Adiabatic Logic for Leakage Reduction

Abstract:

Scaling down sizes of MOS transistors has resulted in dramatic increase of leakage currents. To decrease leakage power dissipations is becoming more and more important in low-power nanometer circuits. This paper proposes a gate-length biasing technique for complementary pass-transistor adiabatic logic (CPAL) circuits to reduce sub-threshold leakage dissipations. The flip-flops based on CPAL circuits with gate-length biasing techniques are presented. A traffic light controller using two-phase CPAL with gate-length biasing technique is demonstrated at 45nm CMOS process. The BSIM4 model is adopted to reflect the characteristics of the leakage currents. All circuits are simulated using HSPICE. Simulation results show that the CPAL traffic light controller with the gate-length biasing technique attains 20% to 5% energy savings compared with the one using the original gate length 25MHz to 200MHz.

You might also be interested in these eBooks

Micro Nano Devices, Structure and Computing Systems

View Preview

Info:

Periodical:

Advanced Materials Research (Volume 159)

Pages:

180-185

DOI:

https://doi.org/10.4028/www.scientific.net/AMR.159.180

Citation:

Cite this paper

Online since:

December 2010

Authors:

Jian Ping Hu, Yu Zhang

Keywords:

Complementary Pass-Transistor Adiabatic Logic, Gate-Length Biasing, Leakage Reduction, Nanometer Circuits

Export:

RIS, BibTeX

Price:

Permissions CCC:

Request Permissions

Permissions PLS:

Request Permissions

Сopyright:

Citation:

References

[1] Andrew B. Kahng: in Conf. on Design, Automation and Test in Europe (2007), p.1466.

Google Scholar

[2] N. S. Kim, T. Austin, et al.: Computer, Vol. 36 (2003), p.68.

Google Scholar

[3] K. K. Kim, Y. B. Kim, M. Choi, and N. Park: IEEE Design and Test of Computers, Vol. 24 (2007), p.322.

Google Scholar

[4] F. Fallah, M. Pedram: IEICE Transactions on Electronics, Vol. E88–C (2005), p.509.

Google Scholar

[5] A. Abdullah, F. Fallah, M. Pedram: IEEE Trans. VLSI, Vol. 12 (2004), p.140.

Google Scholar

[6] I. Hyunsik, T. Inukai, H. Gomyo, T. Hiramoto, and T. Sakurai: in Proc. ISLPED (2001), p.123.

Google Scholar

[7] J. Halter and F. Najm: in IEEE Custom Integrated Circuits Conf. (1997), p.475.

Google Scholar

[8] F. Hamzaoglu, M. R. Stan: in Proc Int Symp on Low Power Electronics and Design (2002), p.60.

Google Scholar

[9] P. Gupta, A. Kahng, P. Sharma, and D. Sylvester: IEEE Trans. on CAD, Vol. 25(2006), p.1475.

Google Scholar

[10] F. Liu, and K. T. Lau: Electronics Letters, Vol. 34 (1998), p.739.

Google Scholar

[11] Y. Moon and D. K. Jeong: IEEE J. of Solid-State Circuits, Vol. 31(4), p.514–522, (1996).

Google Scholar

[12] J. P. Hu, T. F. Xu, and H. Li: IEICE Trans. on Inf & Sys., Vol. E88-D (2005), p.1479.

Google Scholar

[13] W. Zhao, Y. Cao: in Proc. ISQED (2006), p.585.

Google Scholar

[14] J. P. Hu, T. F. Xu, Y. S. Xia: IEEE MWSCAS (2005), p.1398.

Google Scholar
