Influence of External Tendons on Dynamic Characteristics of Box Girder with Corrugated Steel Webs

Abstract:

Based on Miyamoto’s method, the natural frequency of prestressed box girder with corrugated steel webs considering the impact of external tendons was obtained. And the result was modified based on the finite element model. It shows that: the external tendons will reduce the natural frequency of bridge with reduced range of about 3%. Beneficial references were provided to the layout of external tendons in order to avoid the resonance between the box girder with corrugated steel webs and the external tendons.

• Periodical: Advanced Materials Research (Volumes 163-167)
• Pages: 2131-2136
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.163-167.2131
• Online since: December 2010
• Authors: Jian Bo Chen, Bao Dong Liu, Peng Fei Li
• Keywords: Box Girder with Corrugated Steel Web, Dynamic Characteristic, External Tendon, Resonance

References

[1] Baodong Liu, Haibo Chen and Hongwei Ren: Improvement Study of the Dynamic Characteristics for Concrete Box-Girder with Corrugated Steel Webs(In Chinese). China Railway Science, 29(3), 2008, 29-33.

[2] Y.A. Khalid, C.L. Chan and B.B. Sahari: Bending Behaviors of Corrugated Web Beams. Journal of Materials Processing Technology, 150 (3), 2004, 242-254.

DOI: 10.1016/j.jmatprotec.2004.02.042

[3] Haibo Chen, Baodong Liu and Hongwei Ren: Research on Dynamic Characteristic of Concrete Box-girder with Corrugated Steel Webs(In Chinese). Journal of Highway and Transportation Research and Development, 24 (2), 2007, 80-83.

DOI: 10.1061/jhtrcq.0000197

[4] Baodong Liu, Pengfei Li and Lingxiang Xue: Influencing Factor Analyses of Section Types on Vehicle-bridge Interaction of Concrete Box Girder with Corrugated Steel Webs. ICCTP 2009: 2256-2261.

DOI: 10.1061/41064(358)316

[5] Miyarnoto, Ayaho; Tei, Katsuji; Nakamura, Hideaki; Bull, John W., Behavior of prestressed beam strengthened with external tendons, Journal of Structural Engineering. 126(9), 2000, 1033-1044.

DOI: 10.1061/(asce)0733-9445(2000)126:9(1033)

[6] Xueyu Xiong, Shousheng Wang: Analysis and research of externally prestressed concrete beam vibration behavior(In Chinese). Earthquake Engineering and Engineering Vibration. 25(2), 2005, 55-61.

[7] Junjie Zhang: Research on Dynamic Characteristic of Concrete Box-Girder with Corrugated Steel Webs[D] (In Chinese). Beijing：Beijing Jiaotong University, (2009).

[8] Jiaheng Zhang, Liwei Sun and Xiaoguang Feng: Influences of External Prestressing on Vibration Behavior of T-Frame Bridges(In Chinese). Bridge Construction. 4, 2006, 21-23.
