Computer Aided Health Monitoring System for Super-Huge Spacial Cable Structures

Abstract:

Increasingly large and complex structures make it more complicated in analysis, designing and construction, and through the amplification effect caused by the interaction of various parts of the structure, any tiny error in any link could cause huge damage to the building. However, the relative analysis theory and design method are not consummate enough to assess the influence of all kinds of errors. Under this circumstance, structural health monitoring system is an important guarantee to ensure the safety of the structures in both construction and operation stage, and at the same time contributes to make up for the deficiency of theory [1-2]. The Expo Axis project is the largest single project in Expo Site 2010 Shanghai. The Expo Axis project has adopted a whole new architecture form. The roof design as giant light cable-membrane structure about 1000 meter long and about 80 meter width. The computing displacement of the membrane roof is close to 4m. In order to ensure the safety of this structure, a real-time and long-term computer based health monitoring system is applied in the Axis structures.

• Periodical: Advanced Materials Research (Volumes 163-167)
• Pages: 2824-2829
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.163-167.2824
• Online since: December 2010
• Authors: Qi Lin Zhang, Da Lin Li
• Keywords: Computer Based Monitoring System, Expo Axis, Spatial Cable Structure

References

[1] Zhang Qilin. Cable and membrane structure[M]. Shanghai: Tongji University Press, (2002).

[2] Teuffel, P. Smart structures and extreme events[A]: Structures and Extreme Events. IABSE Symposium, 344-5, (2006).

DOI: 10.2749/222137805796271279

[3] L. Chen. Theoretical and practical research of elastic project megnetic method in tensile force measurement in spatial structure [D]. Shanghai: Tongji University, (2007).

[4] Wei Jiandong. Measurement technique in cable force measurement [J]. Journal of China & Foreign Highway, 2001, 21(4): 92-97.

[5] Long Yue, Deng Nianchun. Magniflux and its application in stress monitoring in steel bridge[J]. Prestress Technology, 2007, (2) : 3-6.

[6] L. Chen. Principle and method of measuring cable tension in a cable structure[J]. industrial construction, 2006, 36(Z): 368-371.

[7] Sunaryo Sumitro. Monitoring based maintenance utilizing actual stress sensory technology[J]. Smart Materials and Structure 2005, 12.

[8] Sunaryo Sumitro. Sustainable structure health monitoring system[J]. Structure control and health monitoring, 2005, 12.

[9] Berndt, R. -D.; Schwesinger,P. New generation of the health monitoring system SMS 2001[A]. Proceedings of SPIE - The International Society for Optical Engineering, v 4337, pp.187-193, (2001).
