Friction Loss of Externally Prestressed Concrete Beams with Carbon Fiber-Reinforced Polymer Tendons

Abstract:

Friction loss is an important component of the calculation of prestressing loss for external prestress strengthening technology. Unfortunately, the test data of relevant curvature friction and wobble coefficients is scarce, especially for beams strengthened by external prestressing Carbon Fiber-Reinforced Polymer (CFRP) tendons. Through the experiment of 12 concrete beams strengthened by external prestressing CFRP tendons, this study attempts to discuss the friction loss algorithm and the reasonable value of friction coefficient. The test results demonstrated that traditional friction loss algorithm for prestressed steel tendons is also suit to external prestressing CFRP tendons, but the value of curvature and wobble coefficients should be determined by different types of CFRP tendons and saddle design. What is more, aiming at the domestic production of CFRP tendons and the adopted special saddle design in this paper, the curvature friction coefficient is 0.263 and the wobble coefficient is 0.0067 at the deviator. Results of the research provide a reference for external prestress strengthening design with CFRP tendons.

• Periodical: Advanced Materials Research (Volumes 163-167)
• Pages: 3701-3706
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.163-167.3701
• Online since: December 2010
• Authors: Tian Lai Yu, Li Yuan Zhang
• Keywords: CFRP Tendon, External Prestressing, Friction Loss, Frictional Coefficient, Strengthening

References

[1] Xiantao Zeng and Huimin Che: submitted to Journal of Bridge Construction(2000), In Chinese.

[2] Lieping Ye and Peng Feng: submitted to China Civil Engineering Journal(2006), In Chinese.

[3] The PRC Ministry of Construction : Code for Design of Concrete Structures(GB50010-2002)( China Architecture & Building Press, Beijing, 2002), In Chinese.

[4] ACI Committee 318: Building Code Requirements for Structural Concrete (ACI 318-08) and Commentary (American Concrete Institute, American, 2008).

DOI: 10.1061/(asce)1076-0431(1996)2:3(120.3)

[5] Xueye Xiong: External Prestressing Structure Design (China Architecture & Building Press, Beijing, 2005), In Chinese.

[6] Bo Ding: Statistical Analysis Method of Test Data(Tsinghua University Press, Beijing, 1994), In Chinese.

[7] ACI Committee 440: Prestressing Concrete Structures with FRP Tendons (ACI 440. 4R-04) (American Concrete Institute, American, 2004).

DOI: 10.1061/40753(171)160

[8] JSCE: Recommendation for Design and Construction of Concrete Structures Using Continuous Fiber Reinforcing Materials(Research Committee on Fiber Reinforcing Materials, Japan, 1997).

DOI: 10.14359/4268

[9] Peng Wang, Hanshan Ding and Ruzhen Ding: submitted to Journal of Special Structure(2006), In Chinese.
