Experimental and Finite Element Analysis on the Ultimate Bearing Capacity of Hollow Spherical Joints with Ribbed Stiffener

Abstract:

Four groups (12 in total) of welded hollow spherical joints with ribbed stiffener were tested under uniaxial loads in this paper. With the adoption of elasto-plastic model and consideration of geometric and material nonlinearity, the whole loading process of the specimens was simulated by ABAQUS. Through combining the test data and computing results, two recommendations used to quantitatively determine the ultimate failure load of spherical joint in test are proposed. The relationships between bearing capacity and various influence factors, which include the thickness and diameter of hollow sphere, diameter of steel tube are analyzed and illustrated at the end of this paper.

• Periodical: Advanced Materials Research (Volumes 163-167)
• Pages: 670-675
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.163-167.670
• Online since: December 2010
• Authors: Jiang Tao Yu, Ke Quan Yu, Bo Tang
• Keywords: Hollow Spherical Joint, Influence Factor, Ribbed Stiffener, Ultimate Bearing Capacity

References

[1] JGJ61-2003, Technical Specification for Latticed Shells. (In Chinese).

[2] JGJ 7─91, Specification for design and construction of trussed structure. (In Chinese).

[3] Technical Specification for Spatial Grid Structure (approval of the draft). (In Chinese).

[4] JGJ78-1991, Standard for Quality Inspection and Assessment of Trussed Structure. (In Chinese).

[5] GB50152-92, Standard for Test Methods of Concrete Structures. (In Chinese).

[6] Zhihua Chen, Xiliang Liu: Research on the Bearing Capacity of Welded Hollow Spherical joints, The 11th space structure academic conference, Nanjing, China, 2005. (in Chinese).

[7] Qinghua Han, Yandong Pan, Xiliang Liu: China Civil Engineering Journal Vol. 36 (2003), p.1. (in Chinese).

[8] Nianliang Yao, Ming Dong, Lianping Yang, etc. Building Structure Vol. 30 (2000), p.36. (in Chinese).

[9] Lanchao Jiang, Ri Gao, Guobin Xu. Journal of Northern JiaoTong University Vol. 22 (1998), p.41. (in Chinese).

[10] Minzhou Su, Qiang Gu, Xiaosong Lu. J. Xi'an Univ. of Arch. &Tech. Vol. 30 (1998), p.119. (in Chinese).

[11] Xingfei Yuan, Lizhang Peng, Shiling Dong. Journal of Zhejiang University(Engineering science). (in Chinese).

[12] Wanli Xue, Qilin Zhang. Journal of Building Structures Vol. 30 (2009), p.155. (in Chinese).

[13] Liyi Qin, Degang Xu, Aimin Zhou. Journal of Zhengzhou University Vol. 27 (2006), p.25. (in Chinese).
