The Spline Finite Element Method for the Analysis of the Dynamic Response of Composite Material Plate

Abstract:

Based on Kirchhoff’s classical theory and adoptation the spline finite element method, three independent displacements are interpolated into the anti-symmetric angle-ply laminated plate by the spline base of the cubic spline B function, and the stiffness array and the quality array of the composite material laminated plate are derived. By using Rayleigh-Reeds method, the damping array is established; kinetic equation is derived from Lagrange equation; the response equation is expressed; the inherent frequency of the anti-symmetric angle-ply plate is found by calculation subject to the different proportions of the length to the width, the different number of the layers of the plate and different angles; and the dynamic response problems about the anti-symmetric angle-ply laminated plate are analyzed and solved. Dynamic response problems, such as the displacement, velocity and acceleration, are solved with spline collocation method, through choosing the sample strip functions as mode shape function for various boundary conditions in several numerical examples and the results are compared with Newmark’s method. And better result can be yielded. The example calculations prove the validity of the calculating ways introduced by this paper.

• Periodical: Advanced Materials Research (Volumes 168-170)
• Pages: 1837-1845
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.168-170.1837
• Online since: December 2010
• Authors: Feng Xiang You
• Keywords: Anti Symmetric Angle Ply Laminated Plate, Dynamic Response, Laminated Composite Plates, Spline Finite Element Method

References

[1] Whitney J M. Structural analysis of laminated anisotropic plates[M]. Lancaster: Technomic Publishing Company, (1987).

[2] Jones R M. Mechanics of composite materials[M]. Seconded. Philadelphia. PA: Taylor & Francis, (1999).

[3] Reissner E. A consistment treatment of transverse shear deformations in laminated anisotropic plates[J]. AIAA, 1972, 10(5): 716-718.

DOI: 10.2514/3.50194

[4] Reddy J N. A simple higher-order theory for laminated composite shells[J]. Trans ASME, Appl Mech, 1984, 51: 745-752.

[5] Reddy J N. Exact solution of moderately thick laminated shells[J]. Trans ASCE, Engrg Mech, 1984, 10(5): 794-809.

DOI: 10.1061/(asce)0733-9399(1984)110:5(794)

[6] Noor A K, Buton W S. Stress and free vibration analysis of multilayered composite plates[J]. Composite Structures, 1989, 11: 183-204.

DOI: 10.1016/0263-8223(89)90058-5

[7] Chow TS. On the propagation of fxeural waves in an orthotropic laminated pbates and its response to an impulsive load[J].J. Comp. Mater. , 1971, (5): 306-319.

DOI: 10.1177/002199837100500302

[8] WANG ASD. Chow PC and Rose, J . L.: Strongly coupled stress waves in heterogenous plats[J]. Am INST Aeronart. Astronaut. Jnl, 1972. (10), 1088-1090.

[9] Reddy J. N: On the solutions to forced motions of rectangular composite plates[J]J. Appl. Mech. , 1982, (49): 403-408.

DOI: 10.1115/1.3162101

[10] Mallikarinna and Kant.T.: Dynamics of laminated composite plates with a higher-crder theoryand finite element discretization[J]. Sound Vidr., 1988, (126): 463-475.

DOI: 10.1016/0022-460x(88)90224-6

[11] Kang T., Ravichandran, R. V. Pandy. B.N. and Mallikarjuna: Finitc element analysis of isotropic and fibre reinforced compsiteplates using a higher-order theory[J]. Comp. Strucl. 1988. (9). 319-342.

DOI: 10.1016/0263-8223(88)90051-7

[12] NATHY, MAHRENHOLTZO. Nonlinear dynamic response of a doubly curred shallow shell on an elastic foundation[J]. J Sound &Vibration, 1987, 112(1): 53-61.

DOI: 10.1016/s0022-460x(87)80093-7

[13] Shen Peng cheng. Analysis of the structure of the spline finite element method [M]. Beijing: Hydraulic power press, (1992).

[14] Xu Ci da. Solid mechanics weighted residual method [M]. Shanghai: Tongji university press, (1992).

[15] Bert, C.W. Chen,T. L. C: Effect of shear deformation on vibration of antisymmetrc angle-plylaminated rectangul plates[J]. Int. J. Solide Structuresl. 1978. (14): 465-473.

[16] Xu Bo hou. Based on a new layer and the finite element analysis model of version [J]. Journal of composite materials, 1990, 7(2): 99-109.

[17] Shen Hong yu. Laminated composite material plate of frequency analysis [J]. Journal of composite materials, 1986. 3(2): 64-73.

[18] Reddy J . N: Free vibration of antisymmetric angle-ply laminatd plates including transverse shear deformation by the finie element method[J]. Journal Sound and Vi-bration. 1979, 66(4): 565-576.

DOI: 10.1016/0022-460x(79)90700-4

[19] Shi Zhong ci. The spline finite element [J]. Mathematic calculation, 1979(1): 50~72.
