The Finite Element Analysis of Weight Control Agency Belonging to Crawler Crane Machine

Abstract:

The weight control agency of crawler crane machine may be in the problem of inadequate strength in engineering applications. It will be analyzed and improved design by finite element. The bracket and frame are respectively calculated by static, established the finite element model, imposed loads, solved the result and sum up the stress distribution disciplinarian. The improved agencies are re-analyzed by the ANSYS. After re-analyzed, the intension of the weight control agency meets the strength requirement.

• Periodical: Advanced Materials Research (Volumes 171-172)
• Pages: 778-782
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.171-172.778
• Online since: December 2010
• Authors: Wei Chun Zhang, Jie Chen, Bao Hao Pei, Bing Bing Ma, Peng Yu, Xian Bin Du
• Keywords: Crawler Crane Machine, Improve Design, Static Analysis, Weight Control Agency

References

[1] Gong Shuguang. ANSYS-based applications, and examples of analysis [M]. Beijing: Mechanical Industry Press, (2003).

[2] HAO Cheng-ming. Hoisting the static analysis [J]. Petroleum Engineering Construction, 1981 (1): 32-39.

[3] Zhi-wen. Crane Design Manual [M]. Beijing: China Railway Press, (2001).

[4] LIU Xiang Xin, Meng Yi. ANSYS Tutorial Fundamentals and Applications [M]. Beijing: Science Press, (2006).
