The Realization of 16-Bit PWM for Lithium-Ion Battery Pack Charging by Using C8051F020 MCU

Abstract:

In the lithium-ion battery charging circuits, needs to solve the PWM signal and systems synthesis control item. Therefore, converting voltage feedback signal by C8051F020 MCU ADC0, the result which ADC0 converts delivers the Programmable Counter Array PCA0 module to realize 16-bit PWM trigger signal to control the charging circuit output. At the same time in producing the PWM signal, Use the ADC0 window detector to realize entering value surpassing range alarm and protection, Also, because 12-bit ADC0 is, therefore, Have carried out a recondition on the PCA0 value in program, have realized PWM control signal output, it's frequency is to set up, cause it's application to further nimble, control accuracy more highly.

• Periodical: Advanced Materials Research (Volumes 171-172)
• Pages: 78-81
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.171-172.78
• Online since: December 2010
• Authors: Kai Xu Liu, Yu Bo Duan
• Keywords: C8051, Duty Cycle, Principal Component Analysis (PCA), PWM, System on Chip (SoC)

References

[1] 8051F02X Data Sheets, Cygnal Corporation.

[2] Sheng Saibin, Li Bicheng, Xiao Cheng: Application of SOC Microprocessor C8051F020 Used to Measure and Control System Environment Temperature, Instrument Technique and Sensor，2005. 2: 39-40.

[3] Wang Su: Research on DC Motor PWM Speed Regulation and Its Realization by SCM Control, Mechanical & Electrical Engineering Technology, 2008. 37(18): 82-85.

[4] Lu Dong-Hang, Zhang Dai-run: Realization of Phase-shifting PWM for Soft Switching Based on C8051, Power Supply Technologies and Applications, 2005, 9: 49-52.
