Study on a Flexure Hinge-Based Micro-Displacement Platform

Abstract:

In recent years, a flexure hinged micro-displacement platform driven by piezoelectric actuator is being widely used in vibration suppression and micro positioning applications for its fast response, nanometer resolution, no backlash, no friction and bigger driving force. This kind of precision micro positioning system with a high displacement resolution and wide motion range has been required for industrialized applications for a long time. This paper discusses the design and the characteristics of a flexure hinge-based micro-displacement platform driven by piezoelectric actuator, a four-bar parallel mechanism and a monolithic symmetrical mechanism are adopted in the design. An analytical model is presented and a series of formulae for the static behavior of the platform are derived. Based on the theoretical analysis, the optimum design schema is put forward. The experimental demonstration to study the performance of the platform is described, and the method for reducing nonlinearity errors is proposed. The experimental results are in close agreement with those predicted by the theoretical analysis.

• Periodical: Advanced Materials Research (Volumes 179-180)
• Pages: 1368-1373
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.179-180.1368
• Online since: January 2011
• Authors: Hua Wei Ji, Yong Qing Wen
• Keywords: Flexure Hinge, Micro-Displacement, Piezoelectric Actuator, Platform

References

[1] Smith, S.T. Flexures: elements of elastic mechanisms. Gordon and Breach Science Publisher, (2000).

[2] H. Richter, E.A. Misawa, D.A. Lucca etc, Modeling nonlinear behavior in piezoelectric actuator, Precision Engineering, Vol 25, pp.128-137, (2001).

DOI: 10.1016/s0141-6359(00)00067-2

[3] Goldfarb, M. and N. Celanovic. Modeling piezoelectric stack actuators for control of micromanipulation. IEEE Control Systems Magazine, 1997. 17(3): pp.69-79.

DOI: 10.1109/37.588158

[4] J.M. PAROS and L. WEISBORD. how to design flexure hinges. machine design, 1965(12): pp.151-156.

[5] E. SCIRE, F. and E.C. TEAGUE. Piezodriven 50-μm range stage with subnanometer resolution. Review of Scientific Instruments, 1978. 49(12): pp.1735-1740.

DOI: 10.1063/1.1135327

[6] Gao, P., S. Swei, and Z. Yuan. A new piezodriven precision micropositioning stage utilizing flexure hinges. Nanotechnology, 1999. 10: pp.394-398.

DOI: 10.1088/0957-4484/10/4/306

[7] Jan, C. and C. -L. Hwang. Robust control design for a piezoelectric actuator system with dominant hysteresis. 2000. Nagoya: Institute of Electrical and Electronics Engineers Computer Society.

[8] Holman, A.E. Analysis of piezo actuators in translation constructions. Review of Scientific Instruments, 1995. 66(5): p.3208.

DOI: 10.1063/1.1145552

[9] Yu, Y. Preisach hysteresis modeling for piezoceramic actuator systems. Dissertation of University of Toledo: Toledo, (2000).

[10] Ha, J. -L., R. -F. Fung, and C. -S. Yang. Hysteresis identification and dynamic responses of the impact drive mechanism. Journal of Sound and Vibration, 2005. 283(3-5): pp.943-956.

DOI: 10.1016/j.jsv.2004.05.032
