Research of Rotary Power Head of Drill with Roulette Curve Profile Movable Tooth Transmission

Abstract:

The rotary power head is the most important part of the cutting drill. After researching the status of the rotary power head, we invented a new decelerator—roulette curve profile movable tooth transmission, and applied it in cutting drill, we presented the rotary power head with roulette curve profile movable tooth transmission. The moving components, such as the input shaft and the output shaft, of the roulette curve profile movable tooth transmission are self-balance, so the transmission can bring about random tooth number difference. Analyzing the principle of the transmission, we create the three-dimensional modeling by using Solidworks2010. The rotary power head with the new transmission installed is convenient in assembling and disassembling, transferring bigger torque, having a relatively small radial dimension, suitable for heavy-loaded rock drill machine.

• Periodical: Advanced Materials Research (Volumes 179-180)
• Pages: 851-854
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.179-180.851
• Online since: January 2011
• Authors: You Xin Luo, Heng Shu Li, Hui Jun Wen
• Keywords: Drill, Movable Tooth Transmission, Rotary Power Head, Roulette Curve Profile

References

[1] Youxin LUO, Yangeng LI, Hengshu LI, Huijun WEN: submitted to Applied Mechanics and Materials(2010).

[2] Youxin LUO, Huijun WEN, Hengshu LI: submitted to Applied Mechanics and Materials (2010).

[3] Jifang QU. The Theory of Movable Transmission (China Machine Press, Beijing 1993).

[4] Youyi Zheng, Huifen Sheng. : Mining World, No. 3 (1996), pp.31-34.

[5] Luo Youxin, Liao Degang, Che Xiaoyi, et al.: Transactions of The Chinese Society for Agricultural Machinery, Vol. 39, No. 9(2008) , pp.129-133.

[6] Xie Hong, Shi Wei: Machinery Design & Manufacture, No. 1(2002), pp.35-38.
