Tool with Heavy-Duty Machining Tube Section of the Fatigue Analysis

Abstract:

Because the tube festivals surface is not round, uneven, so the cutting tool is under impact unceasingly in cutting process. Cutting tool is extremely easy to have fatigue failure, therefore it is very necessary to use finite element numerical analysis software ANSYS to carry on numerical simulation analysis for heavy lathe tool intensity static. The force of cutting tool and distributed rule of definite cutting tool internal stress strain could be precisely got by using FEM, thus the analysis results could improve cutting tool stress condition and the structural design provides the theory basis

• Periodical: Advanced Materials Research (Volume 188)
• Pages: 344-347
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.188.344
• Online since: March 2011
• Authors: Zhong Guang Yu, Xian Li Liu, Yuan Sheng Zhai, Geng Huang He, M. Li
• Keywords: Fatigue Analysis, Finite Element Model (FEM), Heavy Lathe Tool, Stress Analysis

References

[1] J.C. Dai, D.C. Luo,Y. Lu and G.P. Wu: J. Wuhan Univ. of Hydr. &Elec. En, vol. 32(1999) No. 5, pp.83-86. (In Chinese).

[2] R.J. Wang: Tool Engineering, vol. 32(2008) No. 7, pp.7-8. (In Chinese).

[3] Z.L. Ning, G.J. Zhang: Tool Engineering, vol. 37(2003) No. 3, pp.13-16. (In Chinese).

[4] Rodd Schuetl: Cutting Tool Engineering, vol. 49(1997) No. 5, pp.57-60.

[5] M.V. Ribeiro: Journal of Materials Processing Technology, vol. 69(1999) No. 4, pp.371-374.
