The Deformation Analysis for Flank Milling of Thin-Walled Rectangle Plate Based on Flexible Force Model

Abstract:

By considering the effects of flank milling deformation on machining quality of thin-walled rectangle plate, the flexible force model of spiral end milling is built on the condition that the influence of part/tool on milling is considered with FE (finite element) numerical simulation method in this paper. Based on the flexible force model, the distribution curve of machining deformation is got by the FE prediction for the flank milling of the thin-walled rectangle plate, and the compensation strategy of CL (cutting location) is established. Some contrast tests between the flexible force model, the deflection simulation and error compensation values to the rigid force model and experimental values of flank milling are performed, respectively. The results indicate that both the flexible force model founded in the paper and the analyzed values of flank milling deflection of thin-walled rectangle plate are reliable, and an effective judgment is provided to advance the machining quality of thin-walled parts.

• Periodical: Advanced Materials Research (Volumes 189-193)
• Pages: 1555-1561
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.189-193.1555
• Online since: February 2011
• Authors: Liang Hong Xiao, Liang Tang, Zi Hua Hu, Zheng Kuang, Ju Long Yuan
• Keywords: Experiment Analysis, Finite Element Prediction, Flexible Force Model, Thin-Walled Rectangle Plate

References

[1] W. J. Endres, R. E. Devor, and S. G. Kapoor: Journal of Engineering for Industry Vol. 117(1995), pp.526-533.

[2] S. Ratchev, S. Liu, W. Huang, and A.A. Becker: Journal of Materials Processing Technology Vol. (2004), pp.153-154: 134-138.

[3] S. Ratchev, S. Liu, W. Huang, and A.A. Becker: International Journal of Machine Tools & Manufacture Vol. 44(2004), pp.1629-1641.

DOI: 10.1016/j.ijmachtools.2004.06.001

[4] J. W. Sutherland and R. E. Devor: Journal of Engineering for Industry Vol. 108(1986), pp.269-279.

[5] Zhigang Wang, Ning He, and Bin Zhang: Aviation Precision Manufacturing Technology Vol. 36(2000), pp.7-11, in Chinese.

[5] Kai Wu, Ning He, and Chengyu Jiang: Journal of Applied Sciences Vol. 21(2003), pp.68-71, in Chinese.

[7] Wei Zhao, Ning He, and Kai Wu: Machine Building and Automation Vol. 5(2002), pp.18-20, in Chinese.

[8] S. Ratchev, S. Liu, and A. A. Becker: Journal of Materials Processing Technology Vol. (2005), pp.162-163: 673-681.

[9] Zihua Hu and Ying Bin: Modern Manufacturing Engineering Vol. 11(2009), pp.81-86, in Chinese.

[10] Budak E and Altintas Y: Int J Mach Tools Manufact Ind Vol. 35(1995), pp.459-476.

[11] L. Kops and D. T. Vo: Annals of the CIRP Vol. 39(1990), pp.93-96 S. Ratchev, S. Liu, and A. A. Becker: Journal of Materials Processing Technology Vol. (2005), pp.162-163: 673-681.
