Numerical Analysis of Controlling Welding Deformation of the Wall Plate of Large Cylindrical Structure by Pre-Stress Method

Abstract:

During the welding of the wall plate of cylindrical structure, the edges of cylinder generates obvious wave-like deformation and affects subsequent assembly. In this paper, based on the numerical simulation method, welding deformation controlling by pre-stress method is studied. The effects of the pre-stress level and the welding sequence on the final deformation are discussed. The results show that the level of pre-stress can obviously control the welding deformation of the longitudinal beams, but can not control the welding deformation of transverse beams. Using the selected welding sequence: welding transverse beams firstly, exerting pre-stress, and then welding longitudinal beams, this welding sequence can reduce the wave-like deformation after welding.

• Periodical: Advanced Materials Research (Volumes 189-193)
• Pages: 3351-3354
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.189-193.3351
• Online since: February 2011
• Authors: Chun Yuan Shi, Qing Yuan Meng, Cheng Jin
• Keywords: Numerical Simulation, Pre-Stress, Welding Deformation

References

[1] Weiyi Zhao, Liequan Liu: J. Huazhong Sci. Technol. Univer. Vol. 29 (2001), p.31.

[2] Shaoqing Guo, Wenli Liu: HANJIE XUEBAO Vol. 20 (1999), p.34. (In Chinese).

[3] Rongbo Fu: Controlling and straighten of welding deformation. (2007). (In Chinese).

[4] Jingyong Li, Mingming Zhang: Hot Working Technol. Vol. 12 (2005), p.15.

[5] Deo M V, Michaleris P: Sci. Technol. Weld. Joining, Vol. 8(2003), p.49.

[6] Deo M V, Michaleris P, Sun J: Sci. Technol. Weld. Joining, Vol. 8(2003), p.55.

[7] L.M. Lobanov and V.L. Pavlovsky, Schweisstechnik (Berlin) Vol. 10 (1987), p.447.

[8] Guangtao Zhou and Xueson Liu: Mater. Sci. Eng. A. Vol. 499 (2009), p.147.
