Modeling Weld Formation Mechanism of Automated Submerged Horizontal Position Arc Welding

Abstract:

An 3D mathematical model was established to illustrate weld pool development in the ASHPW (Automated Submerged Horizontal Position Welding) process. This model takes into consideration the spatial position characteristic of ASHPW, and used the heat transfer and mass transfer phenomena during welding process to explain the weld geometry mechanism in order to correctly design the bevel geometry. The final results show that the predicted geometry , such as the weld cross-section, weld width and weld cross section area, are in good agreement with experimental measurements.

• Periodical: Advanced Materials Research (Volumes 189-193)
• Pages: 3653-3656
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.189-193.3653
• Online since: February 2011
• Authors: Zhi Guo Gao, Yi Jing, Yan Yu, Ding Fu Cheng
• Keywords: Heat Transfer, Sa738GR.B, Spatial Position, Submerged Arc Welding (SAW)

References

[1] C.J. Bolton P.J.E. Bischler and M.R. Wootton, Fracture toughness of weld metal samples removed from a decommissioned Magnox reactor pressure vessel, International Journal of Pressure Vessels and Piping, Vol. 79(2002), 685-692.

DOI: 10.1016/s0308-0161(02)00071-6

[2] X.P. Zhang,L. Dorn, Investigation on the possibility of using the microshear test a surveillance method to estimate the mechanical properties and fracture toughness of nuclear pressure vessel steel, A508CL3, and its joints welded by narrow-gap submerged-arc welding, International Journal of Pressure Vessels and Piping, Vol76(1999).

DOI: 10.1016/s0308-0161(98)00097-0

[3] S.P. Kumaresh Babu, S. Natarajan. Influence of heat input on high temperature welding corrosion in submerged arc welded power plant carbon steel. Materials and Design, Vol 29(2008) , 1036-1042.

DOI: 10.1016/j.matdes.2007.04.009

[4] M.M. Mahapatra, G.L. Datta, B. Pradhan et al, Three-dimensional finite element analysis to predict the effects of SAW process parameters on temperature distribution and angular distortions in single-pass butt joints with top and bottom reinforcements, International Journal of Pressure Vessels and Piping, Vol 83(2006).

DOI: 10.1016/j.ijpvp.2006.07.011

[5] Zhengwei, The simulation of quasi-steady reaction zone submerged arc weld pool thermal field and flow field, Master thesis, Jiangsu University of Science and Technology. (2008).

[6] Guo xiaokai, Li peilin, Chen Junmei et al, Inversing parameter values of double ellipsoid source model during multiple wires submerged arc welding by using Step Acceleration Method, Transactions of the china welding institution, Vol. 30(2), 2009, 53-56.

[7] Zhiguo Gao, Jian Huang, Yixiong Wu. Analysis of weld pool dynamic during stationary laser-MIG Hybrid welding. International Journal of Advanced Manufacturing Technology. DOI 10. 1007/s00170-008-1896-4.

DOI: 10.1007/s00170-008-1896-4

[8] Zhiguo Gao, Jian Huang, Yixiong Wu. Analysis of weld formation mechanism and weld pool dynamic during moving laser-MIG hybrid welding. Applied Mechanics and Materials. Vols. 34-35, 2010, 33-34.

DOI: 10.4028/www.scientific.net/amm.34-35.33

[9] C. -H. Kim, W. Zhang, and T. DebRoy, modeling of temperature field and solidified surface during gas-metal fillet welding, Journal of applied physics, Volume 94, Number 4, 2003, 2667-2679.

DOI: 10.1063/1.1592012

[10] Dhas，J.,E.,R., Kumanan, S. Weld quality prediction of submerged arc welding process using a function replacing hybrid system, Advances in Production Engineering &Management5(2010)1, 5-12.

[11] Wu gansheng, Submerged arc welding, Liaoning science and technology press, 2007, 181-182.
