Influences of Moisture Expansion on Motion Errors of Granite Hydrostatic Guideways

Abstract:

Granite is a kind of high damping material with low thermal expansion, so it is widely used in aerostatic guideways. However, moisture expansion may occur when the granite works in a moist environment, so the applicability of granite to oil hydrostatic guideways is investigated in this paper. By error modeling for a typical closed hydrostatic guideway with four pads, it is shown that the motion errors are mainly determined by geometric errors of the rails when film stiffness of each pads are equal. Experiments on rails of Jinan Dark Green granite are carried out, and the results show the rail straightness variation by the moisture expansion may be less than 1μm/300mm. According to the previous analysis on the error averaging mechanism of hydrostatic guideways, the motion straightness variation may be less than 0.1μm/300mm. In addition, the thickness variation may be less than one ten-thousandth of the rail thickness and the viscosity of liquid has little influence on the moisture expansion.

• Periodical: Advanced Materials Research (Volumes 189-193)
• Pages: 4339-4345
• DOI: https://doi.org/10.4028/www.scientific.net/AMR.189-193.4339
• Online since: February 2011
• Authors: Fei Xue, Wan Hua Zhao, Yao Long Chen
• Keywords: Granite, Hydrostatic Guideway, Moisture Expansion, Motion Error

References

[1] S.Y. Jeon, K.H. Kim: Proceedings of the Institution of Mechanical Engineers Part C-Journal of Mechanical Engineering Science. Vol. 218(3) (2004), pp.309-316.

[2] P. Schellekens, N. Rosielle, H. Vermeulen, et al: CIRP Annals-Manufacturing Technology. Vol. 47(2) (1998), pp.557-586.

DOI: 10.1016/s0007-8506(07)63243-0

[3] P. Sriyotha, K. Nakamoto, M. Sugai, et al: CIRP Annals-Manufacturing Technology. Vol. 55(1) (2006), pp.381-384.

DOI: 10.1016/s0007-8506(07)60440-5

[4] Nanotech 350FG brochure on http: /www. nanotechsys. com.

[5] Nanoform 700 ultra brochure on http: /www. precitech. com.

[6] S. Mekid: International Journal of Machine Tools&Manufacture. Vol. 40(7) (2000), pp.1039-1050.

[7] C.H. Park, Y.J. Oh, E. Shamoto, D.W. Lee: Precision Engineering. Vol. 30(3) (2006), pp.299-305.

[8] L. Montagna, M. Scapin, R. Picozzi, E PATENT 0687533A1. (1995).

[9] M. Valente, J. Burge, R. Dicenso, et al: Proceedings of SPIE. Vol. 4451 (2001), pp.174-180.

[10] X.C. Luo, K. Cheng, D. Webb, F. Wardle: Journal of materials processing technology. Vol. 167(2-3) (2005), pp.515-528.

[11] Y. Wan, Z.Q. Yao, J. Hu, J. Yao: Machine design and research (in Chinese). Vol. 24(6) (2008), pp.109-112.

[12] W.H. Zhao, Y.L. Chen, Z.Y. He, F. Xue, et al, Chinese Patent CN101829904A (2010).

[13] E. Krause, in: Fluid Mechanics, Berlin, Germany: Springer (2005), in press.

[14] W. B. Rowe, in: Hydrostatic and Hybrid Bearing Design, London, UK: Butterworths (1983), in press.

[15] S.T. Smith, D.G. Chetwynd, in: Foundations of ultraprecision mechanism design. Philadelphis, USA: Gordon and breach (1992), in press.

[16] F. Xue, W.H. Zhao, Z.W. Wang, Y.L. Chen, et al: Proceedings of CIRP 2ND international conference process machine interactions. (2010), p. M27.
